Horizontal two stage axially split API 610 high working pressure stainless steel pump
- XINGANG
- T/T
You May Like
-
Horizontal centrifugal axially split two stage heavy oil transfer pump
-
Horizontal double suction cooling water circulating duplex stainless steels pump
-
Horizontal double suction water resources carbon steel pump
-
Horizontal double suction water circulating pump
-
API 610 Horizontal centrifugal double suction water circulating big flow pump
-
Horizontal high flow axially split water resources Austenitic stainless steel pump
Product Details
Place of Origin | Liaoning, China | Brand Name | DK | |
Model Number | BB1 | Theory | Centrifugal Pump | |
Structure | Single-stage Pump | Usage | Other, Chemical liquid | |
Power | Hydraulic | Standard or Nonstandard | Standard | |
Fuel | Other, electric | Pressure | High Pressure | |
Application | Other, transfer chemical liquid,industry |
Product Description
This Pump is an axially split, two stage pump designed to the API 610 (BB1) standards. With a double suction first-stage impeller, the pump is a natural solution for many low NPSH, high working pressure applications such as pipeline and transfer services. The pump fills the performance gap between the single stage and multistage pumps.
- Applications:
LNG, Offsites and Waste Treatment, Cooling Water (power), Crude, Product and CO2 Pipeline, Dewatering and Water Supply (mining), Heavy Oil, Oil Sands and Shale, Gas Treating and Sulfur Recovery, Water Supply and Distribution (water), FPSO, Gas to Liquids, Fire Protection - Industries:
General Industries, Mining, Water Resources, Power Generation, Oil and Gas
Performance range:
Size: 1-24 inches
Capacity: 15-4500 m3/h
Head: 10-320m
Temperature: 0-210 °C
Material: Cast steel, SS304, SS316, SS316Ti, SS316L, CD4MCU
Structure features:
Design:Full compliance with API610 8th edition specification
Construction:
1.The casing is axially split with the suction and discharge branches located in the lower half,so it allows the complete pump rotor with bearings to be removed for maintenance without disturbing the main pipework and valves.Short inspection and maintenance times
2.Impeller is symmetrically arranged.Rotor is in hydraulic balance.
3.Double volute casing reduced radial thrust and bearing loads.
4Large branches.Low flow velocities and high forces and moments accommodated.
5.Sizes of seal champer comply with API682 specification.Seal champer is designed to accommodate all single,tandem,dual and cartridge seal configurations.Cartridge seal is standard type.
6.Replaceable wear beings prevent the main components from being worn out.
7.Generous shaft diameter,small span.Reduce shaft deflection.Increase seals and bearing life.
8.Heavy duty rotor bearings.Special stiffness design makes the bearings run reliably.
9.Flexible spacer membrane coupling.
10.Optional instrumentation to monitor temperature,pressure and ib-ration,etc.
11.Welded common baseplate with drain rim.
We have projects all around the world. Our pumps are popular among our clients.
Our Team&Factory
Applications:
The pumps are suitable for pumping clean liquids or liquids with soe tolerance of slight contamination by solids.They are used for pumping liquids for petrochemical process,for water supply and treatment,as marine ballast and cooling water pumps,in sea water desalination plants,for offshore duties.As well as being used for other similar usefulness.SHS pumps can also be used as energy recovery turbines.
Advantages:
1.Wide choice of hydraulic,good NPSHr performance,high efficiency,wide perfect region,power saving and low consumption.
2.Reliability:Every products is well checked before shipment.
3.Manufacture:excellent equipment,high-class staff,top-ranking products.
4.Service:rapid service,lifetime maintenance.
