API610 pump

Specifications

SHIJIAZHUANG DAMEI KINGMECH PUMP CO.,LTD.

Operating data

Sizes DN   25~400mm

Capacities Q up to 2600m³/h

Heads     H     up to 300m

Operating   Pressures      P   up to 5.0MPa

Operating Temperatures   t     -80°C up to +450°C

Application ranges

   For pumping clean or slightly poluted,cold or hot,chemically neutral or aggressive liquids

l  in refineries,petrochemical industy,coal processing and low temperature engineering.

l  in chemical industy,fibre and general processing industries,particularty in paper and pulp industries, sugar industry.

l  in water industry, particularly seawater desalination plants.

l  in heating and air-conditioning.

l  in fossile and nuclear powerstations.

l  in environmental protection engineering.

l  in ship and offshore industries.

Design

Single-stage,horizontal,radially split volute casing pumps with feet on centreline and single-entry radial impeller,end suction branch,radially upwards discharge branch.Depending on operating conditions hydraulic balance provided by front or rear wear rings and balance holes. Casing vover with cooling or heating connections.Shaft sealing by packings or mechanical seals of any design(single or double working),connections for cooling,flushing or sealing liquid.Standardized pipework according to API plans.

Cooling of baseplate pedestal possible.Flanges possible according to DIN or ANSI.Same nominal pressure for suction and discharge flanges.

Direction of rotation clockwise seen from driven end.
