Intelligent xenon power inverter supply --- 5KW (1KW ~ 20KW) :

Our main customer are European customers, such as: Barberan Machinery, Cefla, CML Finishing,Giardina Finishing, G Technologies, Finishmetal, UV-ray,…

XENON ARC LAMP DC POWER SUPPLY--HAMAL

l HPE developed the Xenon Arc Lamp power supply to drive Xenon ARC DC LAMP from 3KW to 20KW with Air or Water cooled system.

l Igniter embedded in DC Power Supply makes this machine unique on the market ; It don’t need an extra igniter to turn on the XENON ARC DC lamp.

l Output power is very stable even the input not stable, the output current ripple is less than 0.7%.

l Ideal for medical, cinema projection and industrial applications (PCB, LCD and PDP) where a stable light source is essential.

l FEATURES AND BENEFITS

HAMAL Features	HAMAL Benefits
No extra igniter	Igniter embedded Short time(within 10 microsecond) to ignite the lamp Ignite voltage was higher than 30KV~50KV Lamp can be turned on at any time
2. True Power Regulator with Magnitude Control	Fully Stepless regulation Minimal power is 5% for long term standby No special algorithm from customer is required
3. Micro-process Dynamic Control	Best efficiency of the Lamp over the time Find the best working point of current and voltage Control and recovery of the external events
4. High-Speed and Soft Switching IGBT	Very fast response 200ms!!! From stand by to full power
5. Phase Balance	Power factor is 96% No inrush current Cos=1
6. Self-diagnostics and Protection	Self-diagnostics Protection technology, OCP,OVP,OTP,LVP

l TECHNICAL SPECIFICATION

HAMAL Specification	Machine Type
	Air Cooled	Water Cooled
Output Characteristics
Maximum Power Output	3KW~10KW	5KW~30KW
Output Voltage DC	20V~200VDC
Output Current DC	200ADC Max
Current Ripple	<0.8%
Input Requirements
24V Maximum Power Consumption	25W (+Contactor Power Consumption)
220V Fan Power Consumption	70W
Main Voltage	400Vac / 230Vac/480Vac/440Vac +/-10%3Phase
Main Current(at 30KW)	3 x 45A
Main Frequency	50~60Hz
Electrical Properties
Power Factor	96%
Ignition Voltage	Up to 30Kv(within 10 microsecond)
Power Line Loading	Symmetrically on 3 Phases
Connection	R, S, T (PE)
Control Range (respect of Max. Power)	5% ~100% Steppless
Power Accuracy	<1%
Maximum Lamp Cable Length	15MT
Response Time	200ms (from stand by to Full Power)
Physical Properties
Ambient Temperature	0~40°C
Relative Humidity	30%~60%
Maximum Cooling Liqid Pressure	N/A		5Bar or 500KPa
Dimension L(mm) x W (mm) x H(mm)	624 x 160 x 342		624 x 160 x 342
Weight (Kg)	21~23		18~21
Installed Position	Horizontal or Vertical		Horizontal or Vertical

Note: Negative or Positive connection of the lamp cannot be connected to the ground!! Also can not reversed!!

l Machine Dimension

l Electrical Diagram:

One Workshop Corner:

Advanced Italian Testing Device:

Points You May Concern:

1. How much energy we save using these ballasts, instead of normal magnetic ballast and capacitor assembly?

2. How much is the normal life of the lamps with these electronic ballasts.

3. If there is any fault in the ballast, do we have to change the whole ballast or we repair these?

4. Is it possible to repair these ballast here locally afterwards?

5. How much is the life of normal UV lamp with the magnetic ballast and the electronic ballasts?

Answer to the Above:

1. normal magnetic ballast is only two phases, our ballast is three phases,

there are no phase loss, saving 33.3%; magnetic transformer efficiency is less than 80%,

our ballast efficiency is higher than 90%2. our ballast can stay at 5% for standby, normal magnetic ballast can stay at 40% only.

3. It is easy to repair the ballasts if there is small problem, just change some spare parts, the design is very compacted. when you see our product, you can understand how is it working.

4. Yes, the life time of the lamp will increase above 20% based on working condition.

Our Projects for Your Reference. : )
