High Current Toroidal Common-Mode Inductor

Product Description

Detailed Product Description
1. Low-profile Power Inductors with Inductance Ranging from 1 to 1, 200uH
2. Similar to coil craft and Toko, Sumida, TDK
3. RoHS.

Low-profile Power Inductors with Inductance Ranging from 1 to 1, 200uH

Specifications:
. Low profile power inductor
. Low DCR leaded power inductor
. Large-current SMD power inductor
. SMD magnetically shield power inductor
. Shielded SMD power chip inductor
. Magnetic shielded surface mount inductor with high current rating
. Low profile and shielded very effective in space-conscious applications
. Low resistance to deep power loss minimum
. Operating temperature: -20 to 85 degrees (contain heating coil)
. Appearance inspection: No external defect by visual inspection
. Terminal strength: After soldering, between copper plate and terminals of coil, push in two directions of X, Y with standing as below conditions. Terminal should not peeled off
. Heat endurance of reflow soldering: 240
. Insulating resistance: Over 100M Ohms at 100V DC between wire and core
. Dielectric strength: No dielectric breakdown at 100V DC for one minute between wire and core
. Temperature characteristic: Inductance coefficient (0 to 2, 000) x 10-6/(-25 to +80) inductance deviation within +/-5.0%, after 96 hours
. Humidity characteristic: In 90 to 95% relative humidity at 40+/-2 and one hour drying under normal condition. Inductance deviation within +/-5.0% after vibration for one hour
. Vibration resistance: In each of three orientations at sweep vibration (10-55-10Hz) with 1.5mm p-p amplitude
. Similar to coil craft and Toko, Sumida, TDK and Murata brands
