Weighing Indicator for Batching Scale

FOB Price

US$ 200 - 300 / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Hunan, China		Brand Name	SUPMETER
Model Number	BST106-H18[F]

Suitable for Hopper Ration Batching Scale with 5-material, Single-speed or Double-speed Feeding.

Power Supply	AC220V±15%
Display	16-bit green VFD digit display screen with English character display
Kaypad	8 keys for Menu&Shortcut mode operation with key tone
Excitation Voltage Output	DC10V
Max. Connect number of Loadcell	8 Loadcells (350Ω)
A/D Convert	24-bit
Sampling Frequency	800Hz
Zero Drift	±0.1μV/°C RTI (Relative to Input)
Gain Drift	±5ppm/°C
Non-linearity	±0.01%FS
AO	1 AO (4~20mA) for additional option
DI	7 Normally Open Switch Inputs
DO	12 Normally Open Transistor Switch Outputs
Communication Port	COM1: RS232; COM2: RS232/RS485/RS422/Profibus-DP/CANBUS/Ethernet modules for additional option
Connectable	IPC/PLC, Remote Display&Operation Terminal, Serial Printer and Wireless Module
Outline Dimension	164× 82 × 188 mm (W×H×D)
Weight	Approx. 1.5kg
Service Temperature	-20°C to +40°C
Storage Temperature:	-30°C to +60°C
IP Grade	IP50

Certification:

Changsha Supmeter Technological Co., Ltd.: Contact nameLisa Ho
Chat Now; Phone86-731-85115100; AddressBuilding A6, Lugu International Industrial Park, Changsha, Hunan

Application	Auto-checkweigher	Dynamic Axle Weighing Controller	Explosion-proof Weighing Controller
For Belt Weigher	Force Mesuring Controller	Hopper Ration Batching Weighing Controller	Hopper Weighing Controller
Multi-function indicator	New Products	Ration Packing Scale	Shovel Loader Weighing
Simple indicator	Static Weighing Controller	Weighing enclosure
