Home > Products > Dynamic Axle Weighing Controller > Axle weighing controller indicator explosion-proof
Axle weighing controller indicator explosion-proof
Negotiable
/ Piece
1 Piece(Min.Order)
- 1000 Piece / Pieces per Month
You May Like
Product Details
| Place of Origin | Hunan, China | Brand Name | SUPMETER | |
| Model Number | dCX-106C11 | Type | Truck Scale | |
| Power Supply | AC220V/DC24V | Display Type | LED/VFD display |
Product Description
Specifications
1. With multi-functions,2. With explosion-proof shell;
3. With good accuracy and stability;
4. Strong technical support
| Power Supply | AC220V/DC24V |
| Display | B21: LED display; C21: VFD display |
| Keypad | 6 explosion-proof keys for Menu&Shortcut mode operation with key tone. |
| Excitation Voltage Output of Loadcell | DC10V |
| Max. Connection Quantity of Loadcell | 8 Loadcells (350Ω) |
| A/D Convert | 24-bit |
| Sampling Frequency | 200Hz |
| Zero Drift | ±0.1μV/°C RTI (Relative to Input) |
| Gain Drift | ±5ppm/°C |
| Non-linearity | ±0.01%FS |
| AO | 1 AO (4~20mA) for additional option |
| DO | 4 Normally Open Relay or Transistor Switch Outputs |
| DI | 3 Normally Open Switch Inputs |
| Communication Port | COM1: Fixed configuration RS232 or RS485. COM2 Optional: RS232/RS485/RS422/Profibus-DP/CANBUS/Ethernet modules. |
| Connectable | IPC/PLC, Remote Display&Operation Terminal, Serial Printer and Wireless Module. |
| Report Print | Hopper Weighing Report, Ration Feeding&Batching Report and Axle Weighing Report can be printed. |
| Outline Dimension | 340 *390* 205 mm (W*H*D) |
| Weight | Approx. 19.2kg |
| Service Temperature | -20°C to +40°C |
| Storage Temperature | -30°C to +60°C |
| Relative Humidity | Max. 85%RH |
| IP Grade | IP65 |
Application Environment of Model Explosion-proof
Explosion gas environment: Zone 1&2.
Classes of explosion gas mixture: IIA, IIB.
Temperature grades of explosion gas mixture: T1~T6.
Ex-mark: Ex d IIB T6 Gb.
