Series RCDD Dry Self-Cleaning Electric Magnetic Tramp Iron Separator for Coal Port
- Qingdao
- T/T
You May Like
-
CE Certificate Series RCYZ Permanent Pipeline Self-cleaning Iron Separator for Cement Industry
-
in China Series RCYB Suspension Permanent Iron Separator for Vibrating Conveyor
-
Mining Machinery Series RCYB Suspension Permanent Iron Separator for Vibrating Conveyor
-
Newest Technology Series RCYB Suspension Permanent Iron Separator for Vibrating Conveyor
-
For Conveyor Belt Series RCYB Suspension Permanent Iron Separator for Vibrating Conveyor
-
CE Certificate Series RCYB Suspension Permanent Iron Separator for Vibrating Conveyor
Product Details
| Condition | New | Type | Magnetic Separator | |
| Production Capacity | 98% | Place of Origin | Shandong, China | |
| Brand Name | GUOTE | Model Number | RCDD | |
| Voltage | 220V/380V | Power(W) | 10KW | |
| Dimension(L*W*H) | Dimension Size | Weight | 0.9-7.8t | |
| Certification | ISO9001:2008 | Warranty | 12 Months | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Series RCDD dry Self-Cleaning Electric Magnetic Tramp iron Separator for Coal port
Summary
RCDD series self-cleaning electromagnetic separator is used for automatically removing particles and block scrap iron in the non magnetic material.It adopts electrical resin casting and self-cooling sealed structure. There are several advantages :large penetration depth, strong suction, dustproof, waterproof and corrosion resistance . Moreover, it can still work in harsh environments.
Application:
It is used to eliminate the powder or massive waste iron from the nonmagnetic material. The inner adopts the special resin to cast with wholly sealed structure. It features with deep revealed magnetic depth, strong magnetic force, dust-protection and rain-protection, erosion wearing and so on. It can be operated in the harsh environment.
Specifications of cement vibrating feeder
Model | Belt width (mm) | Suspension heighth (mm) | Magnetic field intensity (>mT) | Material depth (<mm) | Excitation power (<kw) | Driving power (<kw) | Belt speed (<m/s) | Weight
| Appearance size (mm) | ||
|
|
|
|
|
|
|
|
| A | B | C |
RCDD-5 | 500 | 150 | 60 | 100 | 1 | 1.5 | 4.5 | 950 | 2020 | 1040 | 775 |
RCDD-6.5 | 650 | 200 | 70 | 150 | 2 | 2.2 |
| 1490 | 2275 | 1190 | 820 |
RCDD-8 | 800 | 250 |
| 200 | 3 | 2.2 |
| 1770 | 2540 | 1480 | 865 |
RCDD-10 | 1000 | 300 |
| 250 | .5 | 3.0 |
| 2380 | 2750 | 1635 | 940 |
RCDD-12 | 1200 | 350 |
| 300 | 5.8 |
|
| 3170 | 3000 | 1800 | 1010 |
RCDD-14 | 1400 | 400 |
| 350 | 6.7 | 4.0 |
| 4800 | 3500 | 2050 | 1050 |
RCDD-16 | 1600 | 450 |
| 400 | 9.5 | 5.5 |
| 6300 | 3900 | 2450 | 1180 |
RCDD-18 | 1800 | 500 |
| 450 | 12.5 | 7.5 |
| 7800 | 4400 | 2850 | 1290 |
Features
1 By using the computer simulation magnetic circuit design, through magnetic depth, magnetic force is strong.
2 Special duct design, coil heat faster, low temperature.
3 Coil adopts advanced insulation processing technology, with its anti corrosive.
4 Automatic discharging iron. Easy maintenance, belt automatic correction
5 Product good compatibility, complete function.
PACKAGING & SHIPPING
1 Packaging: Specially made wooden boxes and containers
2 Shipping: twenty days after receiving initial payment
OUR SEVICES
1 We will provide non metallic ore EPC turnkey project services.
2 According to customer's requirement, you can customize your private model.
3 You can make the complete test
4 We will respect your reasonable requirements
COMPANY INFORMATION
Weifang GUOTE Mine Equipment . is professional and modern enterprise including research and development, engineering design, production and installation, debugging services , automatic control equipment, non-metallic mineral production line test, design, consultation and the complete line of delivery.The scope of services related to mining, metallurgy, electric power, coal, glass, paper, chemical building materials, refractory materials, tiles,food, cement ,etc.Our product sell well in more than thirty provinces, autonomous region.
Our product have electromagnetic, permanent magnetic separator, dry wet magnetic separator,electromagnetic vibration feeder, quartz sand making machine, air classifier, dust collector, water separator, washing machine, flotation machine,metal detector, screw conveyor, timing quantitative feeding,weigher and centralized control system, etc.
Facing the new opportunities and challenges, the company in line with the spirit of "honesty-oriented, mutual benefit, cooperation and innovation" , dedicated to providing “dependable,simple and efficient” products and services to customers, make enterprises become domestic advanced mining equipment manufacturer.
Our company is willing to work together with people from all walks of life for a better future.
FAQ
1.What main products do you supply?
l Ball mill with air classifier production line
l High pure sand making machine
l Air classifier
l Dust collector
l High gradient vertical ring magnetic separator
l Plate type magnetic separator
l Roller type permanent magnetic separator
l Metal detector
l Vibrating feeder
2 Are you a trading company or factory?
We are professional manufacturer of non-metallic minerals
EPC dressing turnkey service in Shandong,China. You are
welcome to visit our factory and discuss for further
business.
3 Delivery date for my order?
10 to 15 days for small size machine; 30 to 40 days for large
size machine.
4 How about your payment methods?
Our payment methods are T/T, Western Union, Money Gram,
Cash, Paypal etc.
5. How do you handle the shipment for my order?
Express, we offer express service ( DHL, UPS, Fedex, TNT&
EMS), it’s the fastest way to receive your order; Air or Sea, we
can send your order by air or sea. Its the most economic way
to receive your order.
6. What is your company warranty policy?
We offer 12 months warranty. For regular customers, we always offer them lifetime warranty.
7. Do you offer any replacement for my order?
Yes, we will offer you the replacements based on the model and quantity you are going to order.
8. How can I contact to you?
You can contact us by e-mail on alibaba or whatsapp
+86 18678029069
