MCP MDT Safety modular transformer
Negotiable
/ Piece
6 Pieces(Min.Order)
- 200 Piece / Pieces per Month
- Shanghai
- T/T Credit Card
You May Like
-
MCP M20-201 experiment of current transformer
-
MCP M20-101 experiment of voltage transformer / voltage transformer
-
MCP RXI-1 - Variable inductor/adjustable inductor/didactic variable inductor
-
MCP TM206 - TESLAMETER / tesla meter 200mT
-
MCP M21-7000 - analog digital trainer / digital analog trainer kit/trainer analog
-
F5-001 capacitor in parallel connection
Product Details
| Place of Origin | Shanghai, China | Brand Name | MCP | |
| Model Number | MDT | Power | Electronic | |
| Usage | Universal Testing Machine |
Product Description
MDT Safety modular transformer
Features
Both primary coil and secondary coil has safety cover
Primary circuit has standard power socket, fuse and switch
Secondary circuit has 4 mm safety socket and double isolation
| UNITS | |
| PRIMARY COIL MDT-P1 .220V power supply .440T, Max.I 4A .Power socket, switch, fuse .Dimension: 110x90x100mm .Weight: 0.85kg | MDT-P1 |
| PRIMARY COIL MDT-P2 .110V power supply .220T, Max.I 8A .Power socket, switch, fuse .Dimension: 110x90x100mm .Weight: 0.85kg | MDT-P2 |
| SECONDARY COIL MDT-S1 .Consists of 5 windings in series .6T, 12T, 24T, 48T, 96T .Max.I 25A, 25A, 13A, 6.6A, 3.3A .4 mm safety socket output .Double isolation .Dimension: 110x90x100mm .Weight: 0.85kg | MDT-S1 |
| SECONDARY COIL MDT-S2 .Consists of 2 windings in series .1000T, 1000T, Max.I 0.8A .Warning: w/o load, the coil delivers 1000V .4 mm safety socket output .Double isolation .Dimension: 110x90x100mm .Weight: 0.85kg | MDT-S2 |
| SECONDARY COIL MDT-S3 .Consists of 2 windings in series .220T, 220T, Max.I 3.6A .Warning: w/o load, the coil delivers 220V .4 mm safety socket output .Double isolation .Dimension: 110x90x100mm .Weight: 0.85kg | MDT-S3 |
| SECONDARY COIL MDT-S4 .Consists of 2 separate coils and each coil has 2 symmetrically windings .12T, 12T, 24T, 24T .Max.I 25A, 13A .4 mm safety socket output .Double isolation .Dimension: 110x90x100mm .Weight: 0.85kg | MDT-S4 |
