Home > Products > Intelligent Lighting Control System > Intelligent smart 12 Channels 15A High-power Dimmer Box Smart lighting system
Intelligent smart 12 Channels 15A High-power Dimmer Box Smart lighting system
- 5000 Piece / Pieces per Month
- Shanghai
- T/T Credit Card PayPal
You May Like
-
Intelligent smart 2 Channels 1.5A CMOS Dimmer lighting controller Module
-
4 Channels 16A Switch Module With 4 ways of 0-10V Dimmer Interface Smart lighting system
-
Intelligent smart Relay switch module for lighting dimmer Controller System 4 channels 16A 3520W Smart lighting system
-
Intelligent smart Relay switch module for dimmer lighting Control System 8 channels 16A 3520W Smart lighting system
-
Ceiling speaker
-
Ceiling speaker
Product Details
Place of Origin | Jiangsu, China | Brand Name | LIENCI | |
Model Number | YT1215A-DB | Theory | Other, Dimmer | |
Usage | General Purpose | Size | Subminiature | |
Protect Feature | Sealed | Contact Load | Low Power |
Product Description
The main features of the system:
- Can seperate-control, central-control and timer manage the lights and curtains in the building by faceplates, mobile phones, pads and PC.
- Have excellent scalabilities. Can be implanted into the standard power monitoring system and air conditioning control system. Provide an effective and convenient firefighting interface.
- Provide friendly control interface and function packs for AMX or Crestron central system.
- Project implementation is simple and clear, there is a clear construction process, the general electric energy in accordance with the construction process will be able to complete the installation and commissioning. Mainte-nance and setting is also very simple and convenient. The maximum reduction of the installation and mainten-nce costs; Installation is easy and clear. General electrician can complete the installation and commissioning according to the construction process. Maintenance and setting are simple and convenient. Installation thresh-old and maintenance cost can be utmostly reduced.
- System can be packed in the mode of electrical closet plus setting touch panel. Electrician can complete the high voltage wiring and the control circuit connections, complete the function settings of the system via the touch panel. The design concept of the system is that, the electrician will be able to complete the installation of the system, he can set up all the control system and application, and fully realize free computer programming.
- The system using the master-slave mode is safe and reliable . In the form of master, lighting gateway can control and manage the terminal. Gateway can achieve the single-control and scene- called, also it has advanced management functions, such as timer function, network information communication, system settings, etc.
- Provide a safe using environment with Unique remote and password login-check.
- Setting data and device’s information can be saved in the gateway in the form of file, which can be read, save and transferred in one-time setup.
SINGLE AREA SYSTEM NETWORK DIAGRAM
Application area:
Commercial buildings, shopping malls, hospitals, schools, hotels, theme parks, gymnasium, exhibition center, residential landscape, building exterior lighting, factory
System functions:
Can single-control, central-control, timer-control the lights, curtains in the system via-control terminals
System characterstics:
System’s openness and compatibility
PPS bus can connect with other systems via RS485 or TCP network port
Standard 35mm DIN-Rail Installation, plug and play, graphical identification, easy to use Safe, reliable, energy conservation
A variety of control modes Safe, reliable, energy conservation System orients to users and managers
System composition:
Din rail type intelligent gateway
Din rail type system power supply
Module: Lighting switch control module, Dimmer module, Curtain control module
Faceplate: Lighting switch and scene control faceplate, Wireless control faceplate, Curtain control faceplate
Sensor: Person sensor, Light sensor, Temp sensor, Weather sensor, Smoke sensor, combustible gas sensor, etc.
Man-machine interface: Computer, mobile phone, wireless touch panel, 3.5 inch wire touch panel, 4.3 inch wire touch panel, 7 inch wire touch panel.
MULTI AREA SYSTEM NETWORK DIAGRAM
Application area:
Commercial buildings, shopping malls, hospitals, schools, hotels, theme parks, gymnasium, exhibition center, residential landscape, building exterior lighting, factory
System functions:
Can single-control, central-control, timer-control the lights, curtains in the system via-control terminals
System characterstics:
System’s openness and compatibility KSL bus can connect with other systems via RS485 or TCP network port Standard 35mm DIN-Rail Installation, plug and play, graphical identification, easy to use Safe, reliable, energy conservation A variety of control modes Safe, reliable, energy conservation System orients to users and managers
System composition:
Din rail type intelligent gateway
Din rail type system power supply
Module: Lighting switch control module, Dimmer module, Curtain control module
Faceplate: Lighting switch and scene control faceplate, Wireless control faceplate, Curtain control faceplate
Sensor: Person sensor, Light sensor, Temp sensor, Weather sensor, Smoke sensor, combustible gas sensor, etc.
Man-machine interface: Computer, mobile phone, wireless touch panel, 3.5 inch wire touch panel, 4.3 inch wire touch panel, 7 inch wire touch panel
