DC12V sound control IR music audio controller rgb

  Product Details

Music controller is a universal type of high performance power controller, adopts the most advanced

PWM (pulse-width modulation) control technology.Can be controlled by persistence of pressure

full-color LED lighting products.

 Product Features:

This controller allows you to have RGB LED lights flash, fade and dance to the beat of music.

Uses 12V input power and has 3 RGB outputs that allows you to hook three different LED strips.

You can also set the lights to flash like christmas tree lights without music. With this controller you have the

option to choose between 15 colors to either stay solid, stay solid white, flash, fade, vary brightness,

dance to the beat of music (2 settings). This controller comes with a full function Wireless Remote to control the unit.

 Specifications:

Working Voltage:DC12V-24V
Output Current:<3A(each channel)
Output: 3 channels
Net weight: 130gWork Temperature:-20-45℃
Rated load current: <3A(each channel)
Remote:IR wireless remote
Output Current: Max.9A for MU108
Control Variant:Common Anode
Sound Control:> 70dB
For control of RGB LED Strips or other products with 12v-24v

Directions of use:

To connect the load line first, then connect the power cord;Before power on to ensure no short

circuit between the cables;

Controller using infrared remote control operation, through the remote control can control the light switch,

16 kinds of color choice, two kinds of dynamic change model, two kinds of acoustic model,

in the static mode can adjust the brightness, can adjust speed in the dynamic model.

Package including:

1 * Remote Control Box
1 * Remote Control
