Product Details
| Place of Origin | Shandong, China | Brand Name | TENSON | |
| Model Number | WDW-10KN | Power | Electronic | |
| Usage | Universal Testing Machine |
Product Description
Specifications
1.universal testing machine2.Celtron load sensor
3.Imported servo driver
puter controller
5.CE ASTM ISO
WDW-Z Series Computerized Electronic Universal Testing Machine for Tensile Compression Bending Shearing Peeling etc
1. Main feasures:
Force range:10KN,20KN,50KN,100KN.
It adopts 7 Inch Touch Screen and computer software TensonTest double display and double control.
High accuracy monitoring :The collecting frequencyis 1000HZ;Control frequency 1000HZ.
High resolution:Force,deformation static 300000 codes,dynamic 30000 codes resolution.
Force,deformation,displacement isthree closed-loop controls.
Multiple safety protection function,signal output and feedback real-time monitoring.
2.Main Technical Parameters:
The accuracy grade of tester | 0.5 grade |
Test force measuring range | 2%-100%FS |
the relative error of test force value | ±1% |
Test force resolution | 1/200000 of largest test force |
Deformation measurement range | 2%-100%FS |
Deformation value relative error | ±1% |
Deformation of the resolution | 1/200000 of largest deformation |
Displacement measurement error | ±1% |
Force adjustment error rate control | ±1% of setting value |
Deformation rate adjustment error | ±1% of setting value |
Beam speed adjusting range(mm/min) | 1. 1-500 |
The relative error of beam speed | ±1% of setting value |
The control error of constant force, deformation and displacement | A) Setting value ≥10%FS, under ±0.1% of setting value B) Setting value <10%FS,beyond ±0.1% of setting value |
Available stretch space(mm) | 800 |
Available test width(mm) | 540 |
Power(V) | 220±10% |
Applications of universal testing machine
WDW-Z Series Electronic universal testing machine suits for rubber, plastic, aluminum tube, composite materials, waterproof materials, prevent material,
yarn, fiber, wire and cable, paper, spring, wood, packaging materials, tape material.
To be the world's leading producer of materials testing equipment
We expert in searching and manufacturing of testing machine
We provide perfect test solutions
We focus on quality of testing machine
We offer 24 hours service
We guarantee to our quality
We are your trust partner
