Steel Bar Univeral Testing Machine 600kN 1000kN 2000kN

Specifications

Steel Bar Universal Tensile Testing Machine 600kN, 1000kN, 2000kN

1. Applications:

WAW-2000B Computerized Electro-hydraulic Servo UTM is huge with large load capacity to 2000kN (200Ton). In testing standard, it conforms to ISO15579-2000, ISO679, ISO7438-1985, ISO6892, EN100021-1-2001, ASTM E8M, JIS Z2241-1998, and other international and national specifications, which are suitable for tension, compression, bending, shear and other tests by adding different test fixture for metal and non-metal materials.

2. Main specifications:

2.1 Max. Test force: 2000 KN;

2.2. Measurement range of accuracy: 2%-100%;

2.3. Control range of stress rate: 1-60MPa/S;

2.4. Adjust range of test stress rate: 1N/mm²S^-1-60N/mm²S;

2.5. Adjust range of test strain rate:0.00025/S-0.0025/S;

2.6. Precision of deformation measurement: ±0.5%;

2.7. Precision of displacement measurement: ±1%;

2.8. Control range of displacement rate:0.5mm/min-50mm/min;

2.9. Tensile space: 850mm;

2.10. Compression space: 800mm;

2.11. Clamping diameter of round specimen: φ15-φ70mm;

2.12. Clamping width of flat specimen: 120mm;

2.13. Clamping thickness of flat specimen: 10-70mm;

2.14. Diameter of cutting test specimen: φ10mm

2.15. Diameter of upper and lower plate: φ240mm;

2.16. Piston travel: 250mm;

2.17. Distance of bending roller: 50-550mm; Width of roller: 160mm;

2.18. Deformation measurement: extensometer gauge length: 50mm; deformation 25mm;

2.19. Power supply: 3-phase 4-wire, 380V 50 Hz, total power 6Kw;

2.20. Dimension: Host machine: 1500×910×3380(mm) Control cabinet: 1130×630×850(mm)

2.21. Weight: Host machine 9000kg, control box 200kg.
