24v 10ah li ion battery pack E-bike Battery with 20A Current
- T/T Credit Card
You May Like
Product Details
Place of Origin | Guangdong, China | Brand Name | Neutral | |
Model Number | 24v 10ah 3 | Type | Li-Ion | |
Nominal Voltage | Other, 24v | Size | Other, 142x150x304mm | |
Nominal Capacity | 10ah |
Product Description
Specifications
24v 10ah li ion battery pack E-bike Battery with 20A Current24v 10ah e-bike battery battery
Nominal Voltage: 24V
Rated Capacity: 10Ah min, 10Ah typical
Including to Charger, BMS etc.
Watt-hour rating:240Wh
1. General: Battery with safety circuit and plastic grid
Model: KY-2410-A
Dimension: 142x150x304mm (WidthxLengthxHeight)
Weight: approx. 2.8Kg
2. Electrical Specification:
Nominal Voltage: 24V
Rated Capacity: 10Ah min, 10Ah typical
Watt-hour rating:240Wh
Charging Method: Constant Current + Constant Voltage
Max. Charge Voltage [V]:29.4 (+/- 50mV)
Max. Continuous Charge Current: 10A
Rec. Charge cut off: by current 8mA or timer 6.0h
Max. Continuous Discharge Current: 20A
Rec. Discharge cut off: 21.0V
Exp. Cycle Life: 300 cycles above 70% of initial cap.(1C @ 20 degree centigrade)
Cell protection Overcharge Detection: 12.65+/-0.025V (0.5 to 1.5 sec. delay, resume 4.15+/-0.05V or @discharging current)
Overdischarge Detection: 2.30+/-0.05V (0.1 to 0.2 sec. delay, resume 2.90+/-0.1V)
Overcurrent Detection: 1.35A to 1.5A (5 to 30msec. delay @discharge)
3. Ambient Conditions
Temperature Range - Charge: 0 to +45 degree centigrade
- Discharge: -10 to +60 degree centigrade
- Charge Retention/Storage [%]: 1 year at -20 to +25 degree centigrade 3 month at -20 to +40 degree centigrade
Humidity: 65+/- 20% RH
Advantages:
1, High energy density
2, High working voltage for single battery cells
3, Pollution-free, environment friendly
4, Long cycle life; It extends its cycle life up to 800 cycles
5,Capacity, resistance, Voltage, platform time consistency is good
6, Simplifying battery management system (BMS) and battery charger
7, With short-circuit production function, safe and reliable
8, Factory price& High quality
9, Fast charging
10, Light weight, small size
11, Large overcharge tolerance and safe performance
12, Self balance
Applications:
1 .Large-scale electric vehicles: such as bus, electric car, tourist car and commix car
2. Light electric car: such as electric bicycle, golf car, small-scale electric flat car, forklift, cleanness car, electric wheelchairs
3. Electric tool: electric drill, electric saw, lawn mower
4. Remote control cars, boat, aircraft, toys,
5. Solar and wind power generation energy storage devices
6. UPS emergency lights, warning lights and miners lamp
8. Small medical equipment and portable equipment
Others:
1, OEM orders are available
2, Superior quality and cost-performance ratio
3, Tags, plugs and connectors are available
4, We could design and produce the battery pack with aluminum alloy shell and assembly procession for customized configurations is available (we could design and develop Li-ion battery according to your product work performance & structure appearance)
5, Bulk pack is available
