High Quality and Cheapest 3500L-5000L Commerical Brewery System
- QINGDAO PORT CHINA
- T/T
You May Like
-
Stainless Steel 5000L Commerical Beer Fermentation Tank
-
5000l Stainless Steel Beer Brewery Plant for Sale
-
5000L Stainless Steel Ale Beer Brewery Equipment for Sale
-
5000l Industrial Beer Brewing Plant for Sale
-
5000l Beer Production Equipment With High Quality
-
5000l Beer Brewing Equipment for Small Factory
Product Details
| Condition | New | Place of Origin | Shandong, China | |
| Brand Name | Tiantai | Model Number | 2000L-5000L | |
| Processing Types | Alcohol | Voltage | 380V | |
| Power(W) | 15-70Kw Depends | Dimension(L*W*H) | Capacity | |
| Weight | 1~5 Tons | Certification | CE ISO | |
| Warranty | 3 Years | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
High quality and cheapest 3500L-5000L commerical brewery system
Introduction of commerical brewery system
A commercial brewery is focus on regional market. The capacity request is not so high than micro breweries. Their beers are
always sold on shelf in bottle or canning. We are involved in providing different types of medium scale industrial breweries to
clients worldwide. The output is mainly 15kL, 20kL, 30kL, 50kL per working day. The complete setup of these breweries is in
compliance with modern brewery standards and specifications. These products enable systematic execution of milling,
mashing, fermentation, filtration, filling and other related processes. We subject each brewing system to stringent testing
procedures before launching them in the market.
Specification of commerical brewery system
Output/Brew | 2kL | 2.5kL | 3kL | 3.5kL | 5kL |
Brews/Day | 2~3 | 2~3 | 2~3 | 2~3 | 2~4 |
Output/Month | 120~ 180kL | 150~ 225kL | 180~ 270kL | 210~ 315kL | 300~ 600kL |
Electric Supply | 3phase/380(220, 415,440)v/50 (60)Hz | ||||
Heating Source | Steam/Directly Fired | ||||
Area Request | >300M2 | >350M2 | >350M2 | >400M2 | >700M2 |
Brewmaster | 3 | 3 | 3 | 3 | 5 |
Configuration of commerical brewery system
Malt Milling Unit
Particle adjustable rolling crusher for dry or wet milling
Flexible or steel auger or a bucket type conveyor to directly lift the milled grain to mash tun
Brewhouse Unit
Mash tun, Lauter tun, Boiling Kettle, Whirlpool tun in various combination
Hot water tank and cold water tank for optional in special combinations
Infusion or decoction brewing methods are designed exactly
Stainless steel cladding is even the unique because of easy maintenance and clean
Two stages or single stage heat exchanger for wort cooling
Completely stainless steel integrated work platform
Sanitary and efficiency wort pump
All pipings, pipes maniford and fittings
Fermentation Unit
Standard stainless steel conical cylindrical fermentation tanks
Single, double, triple or more size as brewhouse is common used in commercial breweries
Tanks quantity is exactly calculated by fermentation cycle for various beers
Roof walkway is for special request
All manhole, valves, pressure gauges, fittings etc are included
Controlling Unit
Electrical controlling cabinet with temperature, on-off controlling for brewhouse
Electrical controlling cabinet with temperature, on-off controlling for cooling parts
Temperature controller, thermocouple, solenoid valves etc are included
PLC with touch screen panel for special request
Beer Dispense
Semiauto or automatic bottling machine with rinsing, filling, capping, labeling etc
Semiauto or automatic canning machine
Flash pasteurizer or tunnel pasteurizer is available
The welding of commerical brewery system
Other products for your reference,plecse click follow links
OEM 1000L-3500L microbrewey system for sale
Welcome your inquiry
