Top quality professional lifting construction building hoist From Factory
- 200 Set / Sets per Month
- Dalian or any other ports in China
- T/T Credit Card
You May Like
-
High safety coefficient slef climbing Construction used tower crane
-
High mechanical strength pulley wheels for crane pulley and wire rope
-
Good Quality for china supplier electric power cable
-
Factory customized passenger hoist , construction building hoist passenger
-
China tower crane manufacturers wholesale supply tower crane spare parts
-
China supplier sales 4D3V2 trolley winch
Product Details
| Condition | New | Place of Origin | Liaoning, China | |
| Brand Name | SYM | Model Number | building hoist | |
| Rated Loading Capacity(kg) | - | Hoisting Speed | 0-96m/min | |
| Max Lifting Height | 580m | Dimension(L*W*H) | - | |
| Loder Weight | 2000kg | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Technical data of SC series genernal hoist
Classification | Model | capacity(kg) | lifting speed(m/min) | motor power(KW) | counter weight(kg) | |
single cage
| with counter weight
| SCD200 | 2000 | 36 | 2*11 | 1000 |
SCD270TD | 2700 | 36 | 3*11 | 1000 | ||
SCD320TD | 3200 | 36 | 3*11 | 1200 | ||
no counter weight
| SC100TD | 1000 | 36 | 2*11 | / | |
SC120TD | 1200 | 36 | 2*11 | / | ||
SC200TD | 2000 | 36 | 3*11 | / | ||
twin cage
|
with counter weight
| SCD200/200 | 2*2000 | 36 | 2*2*11 | 2*1000 |
SCD270/270TD | 2*2700 | 36 | 2*3*11 | 2*1000 | ||
SCD320/320TD | 2*3200 | 36 | 2*3*11 | 2*1200 | ||
No counter weight
| SC200/100TD | 2*1000 | 36 | 2*2*11 | / | |
SC120/120TD | 2*1200 | 36 | 2*2*11 | / | ||
SC200/200TD | 2*2000 | 36 | 2*3*11 | / | ||
Technical data of SC series frequency convertible hoist
classification | Model | capacity(kg) | lifting speed(m/min) | motor power(KW) | counter weight(kg) |
with counter weight | SCD200G (SC200/200G) | 2000 | 0-63 | 2*15 | 2000 |
2000 | 0-96 | 3*15 | 2000 | ||
2000 | 0-96 | 2*22 | 2000 | ||
SCD270G (SC270/270G) | 2700 | 0-36 | 3*11 | 1000 | |
2700 | 0-63 | 3*15 | 2000 | ||
2700 | 0-96 | 3*18.5 | 2000 | ||
SCD320G (SC320/320G) | 3200 | 0-36 | 3*11 | 1200 | |
3200 | 0-63 | 3*15 | 2200 | ||
3200 | 0-96 | 3*22 | 2200 | ||
no counter weight | SC100G(SC100/100G) | 1000 | 0-36 | 2*11 | / |
SC120G(SC120/20G) | 1200 | 0-63 | 3*15 | / | |
1200 | 0-96 | 2*18.5 | / | ||
SC200G(SC200/200G) | 2000 | 0-36 | 3*11 | / | |
2000 | 0-46 | 2*11 | / | ||
2000 | 0-63 | 3*11 | / | ||
2000 | 0-96 | 3*18.5 | / | ||
2000 | 0-120 | 3*22 | / | ||
SC270G(SC270/270G) | 2700 | 0-46 | 3*11 | / | |
2700 | 0-63 | 3*15 | / | ||
2700 | 0-96 | 3*22 | / | ||
SC320G(SC320/320G) | 3200 | 0-46 | 3*15 | / | |
3200 | 0-63 | 3*18.5 | / |
Product description
Assembly style cage
l Installation inside the elevator well
l Assembly style cage
l Capacity:2000kg
l MAX. Lifting speed:0-96m/min
l MAX. Erection height: 580m.
Specifications:
l Direct start-up and stop
l Simplicity and cost saving
l Optional hot deep galvanized cage
l Fault detection system.
