8*4 Dump Truck

FOB Price

Negotiable / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

10 wheel dump truck

BASIC SPECIFICATIONS TIPPER TRUCK DRIVING TYPE 8×4
Model	M2633D
Engine	Engine model: Steyr WD12.336
	Type: Diesel, 4-stroke, direct injection engine
	6-cylinder in-line with water cooling, turbocharged & intercooled
	Maximum output according to DIN: 247 KW at 2200 rpm 336HP
	Displacement: 11.596L
	Min. fuel consumption: ≤198 g/kwh
	Displacement criterion: EUR 2
Transmission	Model: Fuller RT-11509C
	Operating type: Manual shift with hydraulic assistant
	Type: With constant-mesh-gear braker
	Constant-mesh: 8 forward & 1 reverse 8 speed shift
Axle	Front axle model: Steyr 6.5T Rear axles model: Steyr 13T
Steering system	Model: ZF8098, (Germany ZF ,made in China)
Electrics	Operating voltage: 24V, negative grounded
Dimensions	Driver’s cab size (mm):	203024902623
	Wheelbase	3600 +1350 mm
	Cargo body size	19.3CBM
Weight in kg	Gross vehicle weight 26000 kg
Performance	Maximum loading capacity 15000kg
	Maximum driving speed (km/h) 92
	Fuel tank capacity (L) 380

Qixing is the leading brand of heavy duty trucks in China, our products are strong, big power, oil saving and most comfortable.

Hubei Qixing Vehicle-Body Limited Company: Contact nameChuandong Zhang
Chat Now; Phone0086-0722-3260735; AddressNo.2,Lieshan Ave, Suizhou,Hubei Province,P.R.China, Suizhou, Hubei
