New Dongfeng 153 Crane Truck/truck With Crane for Sale
Negotiable
/ Set
1 Set(Min. Order)
- Shanghai or Wuhan
- T/T
You May Like
Product Details
| Condition | New | Application | tansportation | |
| Rated Loading Capacity | 5855 | Rated Lifting Moment | 200 | |
| Max. Lifting Load | 5T | Max. Lifting Height | 3 | |
| Span | 360 degreen | Place of Origin | Hubei, China | |
| Brand Name | Dongfeng | Model Number | EQ1161 | |
| Certification | ISo9001,CCC | Warranty | One year | |
| After-sales Service Provided | Overseas service center available |
Product Description
New dongfeng 153 crane truck/truck with crane for sale
| Product | Dongfeng lorry loading crane(van length 5.3m) | |
| Chassis type | EQ1161 | |
| Lifting capacity(T) | 5 | |
| Parameters | Overall dimension length/width/height (mm) | 8530x2470x3525,3405,3375,3325,3125 |
| Total Mass(kg) | 14300 | |
| Payload(kg) | 5655,5755,5855 | |
| Kerb Mass(kg) | 8450,8350,8250,7900 | |
| Approach angle/ Departure angle(mm) | 34/14 | |
| Front suspension/rear suspension(mm) | 1245/2285 | |
| Fuel Type | diesel | |
| Fuel Consumption/100 km | ||
| Max Speed | 90 | |
| Engine | Type | |
| Displacement/Power(kw) | 5880/132(180HP) | |
| Manufacturer | ||
| Type | 4-in-line | |
| Chassis | Drive type | 4×2 |
| Wheelbase(mm) | 5000 | |
| Tread(front/rear) | ||
| Front axle | 5T | |
| Rear axle | 10T | |
| Steering gear | Duel-armed steering wheel, power steering | |
| Transmission | 6 gear mechanical drive transmission | |
| Clutch | Diaphragm clutch, hydraulic remote control, pneumatic servo | |
| Braking system | Split air braking system, spring braking, exhaust braking | |
| Cab | Non-longheaded, one and a half row cab,whole metal-enclosed | |
| Number of spring axle(front/rear) | ||
| Tire Type | ||
| Air-condition | Choose to fix | |
NOTE:
As top cabin and truck manufacturer in China, our product has advantage of “High quality, high reliability, and high stability”
Workshop picture:
Quality certification:
Contact information:
Contact Us
- Hubei Qixing Vehicle-Body Limited Company
- Contact nameChuandong Zhang Chat Now
- Phone0086-0722-3260735
- AddressNo.2,Lieshan Ave, Suizhou,Hubei Province,P.R.China, Suizhou, Hubei
