Home > Products > Generator Set Series > MTU 1000KW NATURE GAS GENERATOR
MTU 1000KW NATURE GAS GENERATOR
- FOB FUZHOU
- T/T
You May Like
Product Details
| Place of Origin | Fujian, China | Brand Name | YANAN | |
| Model Number | YN1250MTU | Output Type | AC Three Phase | |
| Speed | 1500rpm | Frequency | 60HZ | |
| Rated Power | 1000kW/1250kVA | Rated Voltage | 220V/440V | |
| Rated Current | 1987A |
Product Description
MTU 1000KW NATURE GAS GENERATOR
| GENSET MODEL NOS. | YN1250MTU |
| Manufacturer | Yanan |
| Rated speed / frequency | 1500RPM/50Hz |
| Continuous output(KW/KVA) | 1000/1250 |
| Standby output(KW/KVA) | 1100/1375 |
| Voltage, Phase and wire | 400V/230V, 3 Phase and 4 Wires |
| Rated power factor | 0.8(lagging) |
| Dimension(L*W*H) | 4.5X1.6X2.27 m |
| Weight(kg) | 6500 |
| Rating Definitions (Operation at Altitude ≤1000m, Ambient temperature ≤ 40°C) | |
| These ratings are applicable for supplying continuous electrical power (at variable load) in lieu of commercially purchased power. There is no limitation to the annual hours of operation and this model can supply 10% overload power for 1 hour in 12 hours. | |
| Diesel Engine | |
| ENGINE MODEL | 16V165RQS |
| Engine Characters | Water-cooled, 4 cylinders in line, 4-cycle, direct injection |
| The engine output(KW) | 1100 |
| Aspiration | Turbocharged & Aftercooled |
| Bore(mm)×Stroke (mm) | 165*165 |
| Compression ration | 13.9:1 |
| Fuel consumption(L/H) | 202(100% load) |
| Displacement(Liters) | 63.36 |
| Cooling water capacity(L) | 194 |
| Voltage for start(V) | 24 |
| Instrument for adjusting speed | Electronically |
| Noise level(A) | ≤85dBA(open) |
| ALTERNATOR | |
| ALTERNATOR MODEL | SLG404Z |
| Excitation | Brushless |
| Insulation class | H |
| Protection class | IP22 |
| Efficiency | 94.70% |
| Voltage adjust range | ±0.5% with 4% engine governing |
| Steady state voltage regulation | ≤±1% |
| Voltage Control | AVR |
Our Advantages:
1. Reliable Performance: Reliable Performance is the major advantage of YANAN products, and this reliability is based on the outstanding design in every aspect and strict Q.C. System.
2. Customer First: We devote ourselves to develop products to meet customers' requirements .Our engineer develop and design new products for customers.
3. Technical Support and Service: Our engineer team will solve your technical problems within 48 hours.
4. Strict test process before ex-factory: Every product will be tested twice before ex-factory
5. Certification: CE,ISO,UL,TUV,CCS
YANAN GAS GENERATOR SET WITH ADVANCED TECHNOLOGY
Electrical Control and Gas Mix Technology
1. Full capacity output in low methane density condition.
2. Quick response to instantaneous load fluctuation.
Lean Combustion Technology
1. Less gas consumed
2. Lower exhaust temperature which results in longer engine life.
3. Lower annually operating cost
4. Lower emission
5. High efficiency
YANAN ADVANCED GAS TECHNOLOGY WILL BRING YOU HUGE ECONOMIC BENEFIT
There are three popular ways to utilize gas to generate electricity nowadays:
1. Boiler +steam turbine
2. Gas turbine +team turbine
3. Gas engine
Among the three, the third one outweighs the others by having the following advantages:
1. High electrical efficiency
2. Low requirements to gas and load can be adjusted automatically according to gas concentration
3. Wide range of rating
4. Advanced technology assured stable performance
5. Compact structure, small size and light weight make installation and transportation easier.
6. Simple operation and quick start and shut down enable convenient maintenance.
7. Various safety measures warrant reliable performance
8. Flexible accessories
THE ECONOMIC ANALISIS OF CCHP SYSTEM
Take 2sets Yanan G3520C-2000KW as an example to explain CCHP for energy conversion 41.9% will be transferred to electric power,30.76%wii be discharged,22.72%will be taken away by cooling water of engine, and the rest 4.26% will be radiated via engine block and other ways.
(1Investment (pre-processing equipments +biogas generator set +generator set room +switch board):RMB16,600,000
(2)Operating cost per year (maintenance +labor cost);RMB2760000
(3)Economic analysis:
Annual power generation :2000*24*320*2=30720000kw*h
Electricity charging rate=RMB0.5Kw*h
Annual electricity -saving rates:
30720000kw*h*RMB0.5/Kw*h=RMB15,360,000
Investment payoff period:
16,600,000/(15,360,000-2.760,000)=1year and 4months
Further to invest RMB600,000 for CHP System to utilize the exhausted heat from engine,An output of 29,000ton steam will be rewarded per year.If for Stream is @RMB50 per ton,an extra benefit from steam will be as much as RMB1,450,000per year.

Packed & Delivery Time:
Package Detail: Packed in standard seaworthy packing such as air bubble plastic bag
Delivery Time Detail: within 10 days to 28 days (2 or 4 weeks)
