50Hz AND 400Hz DUAL FREQUENCY MOTORS

FOB Price

US$ 100 - 50,000 / Set

1 Set(Min. Order)

Port FUZHOU
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Fujian, China		Brand Name	YANAN
Model Number	SP31A-32

Product Description

50Hz AND 400Hz DUAL FREQUENCY MOTORS

SP series dual frequency alternators can output 380V-440V/50Hz and 200-480V/400Hz power together.
Consist of two alternators in one shaft.

FEATURES:
Steady-state voltage regulation rate not more than 1%;
Transient voltage regulation rate not more than 15% or 20% setting time not more than 0.5s, when mutation rated power load;
Totally-enclosed bearing;
Double bearing support or single bearing support;
Standard: GB755-2008, GJB1213-91, GJB181-86, GJB549-88, ISO6858.

TECHNICAL DATA
Model	Power frequency output
	Prime Output	Voltage	Current	Power factor	Phase number	Frequency
	kW	V	A	lag	Phase number	Hz
SP31A-32	12	380	22.8	0.8	3	50
SP31B-32	12	380	22.8	0.8	3	50
SP31C-32	20	380	38	0.8	3	50

Model	Medium frequency output
	Prime Output	Voltage	Current	Power factor	Phase number	Frequency	Speed
	kW	V	A	lag	Phase number	Hz	rpm
SP31A-32	50	200	180.4	0.8	3	400	1500
SP31B-32	75	200	270.6	0.8	3	400	1500
SP31C-32	100	200	360.9	0.8	3	400	1500

Packing & Delivery

Packaging
Size(m)	1.2×1.0×1.0
Weight	820kg
Packaging Details	* The normal package is wooden box(Size: LWH). * The details relating to packaging and logistics are agreed with the customer.

Our Service

Pre-Sales Service Team

* Correct choice of generator;
* Installation recommendations and to provide technical information;
* Satisfied users of the special design requirements;
* Sample testing support;
* View our Factory.

After-Sales Service Team

* Training of operation and maintenance personnel,and spare parts supply, complete its comprehensive offering.

* Our company has trained a number of high-grade quality professional maintenance team to provide customers with fast and high-quality after-sales service.
