VMS LED Sign Trailer 4colors

VMS LED  sign trailer, 4colors GW-VM 400C

APPLICATIONS

Advanced warning to motorists of roadworks/conditions

School,Pedestrian or Roadwork Zones

Notification of road closures or detours   Used with Radar to display traffic speed

Promotion of Events, e. G Sporting, Festival
Product Advertising, e. G Car Yard, Property Development

FEATURES
Full Graphics Non Glare, UV resistant polycarbonate Highest Quality LED s Solar Powered/Environmentally Friendly Plug & Play controller and LED modules SPECIFICATIONS & TECHNICAL DATA Display Display Type: LED Full Matrix Display Size: 2730mm x 1850mm Display Viewing Area: 2450mm x 1600mm Matrix: 48 x 28, 4 X 5mm LED s per pixel ( GREEN, RED, AMBER, WHITE) or (GREEN, RED, AMBER, WHITE) Enclosure: IP54 equivalent, front access Screen: Non Glare UV polycarbonate Photocell auto dimming

Trailer

L x W x H: 3950 X 2050 X 2700MM (with draw bar, fender)
Operating height: 3950mm Rotating degree for message panel: 360 Draw bar length: A frame type 2200mm Trailer has the brake system for the message panel, so it can stop on the certain position. For corner jack stands: 15 inch, 3000LBS Draw bar jack stand (with 6inch jockey wheel): 2000LBS
Coupler: 5000LBS; 50mm ball Wheel type: 14 inch Disc brake system for the wheel Hydraulic function for operating message panel lift Manual Hydraulic Backup 3mm steel check plate Controller and Programming PC for on site programming Programming options: SMS, RSR232 Serial direct connect Software Windows Compliant Free automatic software updates! !
Predefined Images: 90 Radar: Radar logging / remote removal, logging speed data / time traffic count Large Storage up to 100 individual messages with various page sizes Power Voltage: 12V Solar Panels: 2 x 125 watt Panels Batteries: 3 x 12Volt; 200AH deep cycle Solar Controller: 30AMP Operation on batteries/solar Indefinite under normal conditions
Optional Extras SMS 3G GPS+INTERNET INDUSTRIAL TOUCH MONITOR TABLET PC BATTERY CHARGE SPEED RADAR SOLAR TILTING SYSTEM
