Home > Products > Steel cord conveyor belt > China made ST630 good tensile hot selling conveyor system part steel cord transmission belt

China made ST630 good tensile hot selling conveyor system part steel cord transmission belt

FOB Price

US$ 20 - 50 / Meter

100 Meters(Min. Order)

Port ShangHai
Payment TermsT/T L/C D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China		Brand Name	HuaShen
Model Number	ST630

Product Description

China made ST630 good tensile hot selling conveyor system part steel cord transmission belt

1. steel cord rubber conveyor belt
we are a professional manufacturer of steel cord conveyor belt, Steel cord conveyor belts are widely used in high strength,long distance and heavy load trans- portation of materials.
2.Construction of steel cord rubber conveyor belt
a. Belt reinforced with galvanized steel cord and core rubber with superior adhesive property.
b. Steel cord made of left and right twisting wire arranged evenly and longitudally in the belt.
c. Large tensile strength, excellent troughability and excellent flexing resistance.
3.Advantages of steel cord rubber conveyor belt
a. With high-modulus, low elongation
b. Impact resistance and good truoghability
c. High tensile strength and long working life
4. Application of steel cord rubber conveyor belt
Cement industry, coal mines, quarries, minings, electric power plants, metallurgic industry, ports and chemical industry, etc.

5.Reference Specification of steel cord rubber conveyor belt

Standard belt specification
Belt strength (st-NO.)	Max Cord diam (mm)	composition	Pitch (mm)	Standard working tension (N/mm)	standard cover Thickn esst₁t₂ (mm)	Belt weight(Kg/m₂)	Min.pulley diam(mm)	cord strength KN/piece
St-630	3.0	96×7+IWS	10	90	5×5	19.1	800	6.93
St-800	3.5	K6×7+IWS	10	110	5×5	20.6	800	8.8
St-1000	4.0	K6×7+IWS	12	140	6×6	24.7	800	13.2
St-1250	4.5	K6×7+IWS	12	175	6×6	25.4	800	16.5
St-1600	5.0	K6×19+IWS	12	225	6×6	26.0	1000	21.12
St-2000	6.0	K6×19+IWS	12	285	8×6	30.0	1000	26.4
St-2500	7.2	K6×19W+IWS	15	355	8×6	32.2	1250	41.25
St-3150	8.1	K6×19W+IWS	15	450	8×8	35.7	1400	51.98
St-3500	8.6	K6×19W+IWS	15	500	8×8	44.9	1500	57.7
St-4000	8.9	K6×19W+IWS	15	570	8×8	46.6	1600	66
St-4500	9.7	K6×19W+IWS	16	645	8×8	49	1800	79.2
St-5000	10.9	K6×19W+IWS	17	715	8.5×8.5	53.6	1800	93.5
St-5400	11.3	K6×19W+IWS	17	760	9×9	57.5	2000	101

Horizontal Enhanced Steel Cord Rubber Conveyor Belt

Number of steel cords
belt width mm	St630	St800	St1000	St1250	St1600	St2000	St2500	St3150	St3500	St4000	St4500	St5000	St5400
800	75	75	63	63	63	63	50	50	50
1000	95	95	79	79	79	79	64	64	64	64	59	55	55
1200	113	113	94	94	94	94	76	76	77	77	71	66	66
1400	133	133	111	111	111	111	89	89	90	90	84	78	78
1600	151	151	126	126	126	126	101	101	104	104	96	90	90
1800		171	143	143	143	143	114	114	117	117	109	102	102
2000			159	159	159	159	128	128	130	130	121	113	113
2200						176	141	141	144	144	134	125	125
2400						193	155	155	157	157	146	137	137

Cover rubber property and grades

Test items		Property indexes
		GB9770-2001				DIN22131
		D D	H H	L L	P P	W W	X X	Y Y
Tensile strength	Mpa ≥	18	25	20	14	18	25	20
Pull to break the elongation rate	% ≥	400	450	400	350	400	450	400
after aging(707D) Change rate of tensile strength Change rate of elongation	%	-25+25	-25+25	-25+25	-25+25	-25+25	-25+25	-25+25
Abrasion	≤	90MM³	120MM³	150MM³	200MM³	90MM³	120MM³	150mm³

Adhesion of steel cord

strength	St630	St800	St1000	St1250	St1600	St2000	St2500	St3150	St3500	St4000	St4500	St5000	St5400
Adhhesion N/mm GB9770-2001	60	70	80	95	105	105	130	140	145	150	165	175	180
Adhesion N/mm DIN22131-88	60	70	80	95	105	105	130	140	145	150	165	175	180

GB/79770 Cover property and grade

Item	Tensile Strength ≥MPa	Change rate of elongation ≥%	Abrasion ≤mm³
D	18	400	90
H	25	450	120
L	20	400	150
P	14	350	200
Note:D—under strong abrasion condition;H—under serious laceration condition ;L—under normal condition;P—for oil, hot, acid and alkali, coldness and flame resistant belt

DIN2213 Cover property and grade

Grade	Min Tensile strength MPa	Change rate of elongation ≥%	Abrasion ≤mm³
W	18	400	90
X	25	450	120
Y	20	400	150
K*	20	400	200
Note:*suit for DIN22103 fire resistant belt , and the cover rubber is up to the DIN22104 standard.
