Home > Products > screw barrel for other machine > Bimetallic Mixing Head Screw Screw Barrel
Bimetallic Mixing Head Screw Screw Barrel
- Ningbo
- T/T
You May Like
-
Tungsten Carbide Alloy Screw and Barrel for Plastic Extruder Machine
-
Blowing Mould Machine Alloy Screw Barrel for Single Plastic Extruder Machine
-
Barrel With Barrier Screw/ Screw & Barrel for Plastic Machinery Parts
-
Hdpe Ldpe Lldpe Barrel With Barrier Screw / Screw & Barrel for Plastic Machinery Parts
-
Hdpe Ldpe Lldpe Single Screw and Barrel / Blow Molding Machinery/ Screw & Barrel for Film Blowing Plastic Machinery Parts
-
Bimetallic Screw and Barrel for Epe Ldpe Foam Recycling Machine
Product Details
| Place of Origin | Zhejiang, China | Brand Name | QunYing screw barrel | |
| Model Number | 20 |
Product Description
Mixing head screw
***Grade available:
1. Standard grade: 38CrMoAlA + nitriding 96 hours
2. Bimetallic grade: 38CrMoAlA + bimetallic alloy
3. TC-A grade: Tungsten carbide 40%
4. TC-B grade: Tungsten carbide 25%
5. TC-C grade: Tungsten carbide 15%
***Material for rubber extruder screw barrel for rubber processing machine
1)38CrMoALA(JIS SACM645)
2)42CrMo(JIS SCM440)
3)9Cr18MoV
4)CW6Mo5Cr4V2
5)Various high quality alloy steels,According to different usage, the choose for alloy is different, some require for abrasion-resistant while some require for corrsion-resistant. For standard, we have Fe-based, Ni-based, W2C alloy,Tunsten alloy etc for choice.
6)The foreign material we used as following:
*Germanysteel, GH113 ,2250 ,2842 ,1.8509 ,1.442 ,1.6582 ,1.6523 ,1.2080,1.4542,
*USA steel, P20,420,L6,H13,W110,D3,A2,D6,O1,S1,M35,8620,3115,K52440
*Sweden steel, 718S,718H,S136,S136H,STAVAX,ASP-23,ASP-30
*Australia Steel, M202,M300,W302,K460,W300,K900,K100,W321
*Hardnesssteel, YG6X,YG 6A,YG 6,YG8N,YG8,YG8C,YG11C,YG 15,YT5,YT14,YT30
*Japan Steel, SKT 4,YXM 4,YXM 42,SNC 815,SK -3,SKS 3,and etc.
***Application:
Rubber,various high glass fiber, mineral fiber and PPA,PPS, PA6T, LCP,VO fire protection, ferrous power, magnetic powder and etc. Meanwhile,Used for PVC + 30% CaCo3, recylced plastic material.Technical Parameter |
| Steel Material | DIN 41CrA1Mo7 / AST M4140 / GB 38CrMoAlA |
| Deepness of Nitriding Layer | 0.7 mm -0.9 mm |
| Hardness of Nitriding | HV900 - HV1,000 |
| Nitriding Brittleness | ≤Grade 1 |
| Chromate plating | Thickness 0.05 mm - 0.10 mm, hardness HV950 |
| Special treatment | Carbide coating on screw flight and bimetallic barrel |
| Screw straight tolerance | 0.015 mm/m |
| Surface roughness | Ra 0.4μm |
|
Contact Us
- Zhoushan Qunying Plastic Machinery Manufactory
- Contact nameFeiying Fang Chat Now
- Phone86-580-8340889,8340879
- AddressNo.169 Xindao East road, Jintang Town, Zhoushan,Zhejiang,China, Zhoushan, Zhejiang
