Home > Products > rubber screw barrel > rubber screws barrel for rubber fliter
rubber screws barrel for rubber fliter
USD $200 - $5,000
/ Set
1 Set(Min.Order)
- 1000 Set / Sets per Month
- NINGBO
- T/T
You May Like
-
rubber screw barrel for rubber profile
-
screw and barrel for rubber extruder machines
-
plastic feed screw
-
CHINA Krauss Maffei extruder twin double twin screw barrel with oil cooling
-
air bubble film machine screw and barrel professional manufacturer of screw barrel
-
bimetallic screw barrel for blow moulding machines
Product Details
| Place of Origin | Zhejiang, China | Brand Name | QunYing | |
| Model Number | QY-R01 |
Product Description
Specifications
1.rubber screw and barrel2.Cold /hot feed pin screw
3.Wear-abrasion&corrosion performance
4.longer life
Rubber screw barrel specifically for rubber products,suche as seal strip, rubber foam board, rubber sheet, rubber hose, rubber foam hose, rubber water stop belt, and so on. Raw material is EPDM, SBR, BR, CR, NBR, IIR, silicon rubber and so on.
Tell us your product and your raw materials,we could design for you.
Specification:
1.Cool feeding rubber screw and barrel
Specification: Φ40-Φ300mm, L/D:8-20:1
2.Hot feeding rubber screw and barrel
Specification: Φ30-Φ250mm, L/D:4-8:1
3.Pin rubber screw and barrel
Specification: Φ60-Φ250mm, L/D:12-18:1
Technical Data: | |
Nitride Case Depth | 0.5mm-0.8mm |
Nitride Hardness | 950-1020HV |
Nitride Brittleness | ≤Grade One |
Surface Roughness | Ra0.4um |
Screw Straightness | 0.015mm |
Alloy Hardness | HRC65 |
Alloy Depth | 1.2mm-2.0mm |
Chromium Coating Thickness | 0.03~0.10mm |
Materials:
The most popular materials is 38 crmoala, 42crmo, if you want other materials,you also could choose as the following:
1. Germanysteel, GH113 ,2250 ,2842 ,1.8509 ,1.442 ,1.6582 ,1.6523 ,1.2080,1.4542,
2. USA steel, P20,420,L6,H13,W110,D3,A2,D6,O1,S1,M35,8620,3115,K52440
3. Sweden steel, 718S,718H,S136,S136H,STAVAX,ASP-23,ASP-30
4. Australia Steel, M202,M300,W302,K460,W300,K900,K100,W321
5. Hardnesssteel, YG6X,YG 6A,YG 6,YG8N,YG8,YG8C,YG11C,YG 15,YT5,YT14,YT30
6. Japan Steel, SKD61,SKD11,SKT 4,YXM 4,YXM 42,SNC 815,SK -3,SKS 3,and etc.
And about the treatment of screw barrel, we also have many choices for you:
And about the treatment of screw barrel, we also have many choices for you:
Nitrided
Nitrided+chromium-plating
Bimetallic
Bimetallic+chromium-plating
Bimetallic+chromium-plating
QY-Grade A - containing Tungsten of 40%
QY-Grade B - containing tungsten of 25%
QY-Grade C - containing tungsten of 9.5%
QY-Grade A/B/C + chromium-plating
Application:
Application:
Product show:
ISO Certificate:
SGS Certificate:
