20 liter bottle blow moulding machine
USD $9,000 - $11,000
/ Piece
1 Piece(Min.Order)
- 10 Piece / Pieces per Month
- Ningbo
- T/T
You May Like
Product Details
| Condition | New | Application | Bottle | |
| Plastic Processed | PET | Blow Moulding Type | Stretch Blow Moulding | |
| Automatic | No | Place of Origin | Zhejiang, China | |
| Brand Name | Baixing | Model Number | BX-D1 | |
| Voltage | 380V | Certification | CE | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
60-90pcs/hour20 liter bottle blow moulding machine
3 gallon bottle blowing machine
5 gallon PET bottle blowing machine
Features of 3-5 gallon PET bottle blow moulding machine:
1.Perfect function with economic investment.
2.Small size and compact construction with no space waste.
3.Easy to operate and maintain,operation by one person.
4.Saving power and uneasy to worn out.Adopting new double crank four bars to lock mould,the cross fixed. Providing high pressure blowing system.
5.We can provide performs and cap moulds for 5 gallon and 3 gallon bottle to meet customer's requirements.
Technical parameter:
ITEM | UNIT | BX-D1 |
Cavity | pcs | 1 |
duct capacity | L | 10 |
duct capacity | L | 25 |
Min.inner neck diameter | mm | 55 |
Max.inner neck diameter | mm | 180 |
duct diameter | mm | 300 |
duct height | mm | 470 |
Max.mould thickness | mm | 200-350 |
Mould opening stroke(Adjustable) | mm | 350 |
Theoretical output | bph | 60-100 |
Operating pressure | Mpa | 0.7-1.0 |
Blowing pressure | Mpa | 1-3 |
Heater power | kw | 28.8 |
Machine weight | kg | 1350 |
Heater weight | kg | 350 |
Machine dimension(L*W*H) | m | 2.3×0.85×2.2 |
Heater dimension(L*W*H) | m | 2.35×0.7×1.8 |
