Capacity 400kg vacuum glass lifter

Capacity 400kg vacuum glass lifter/glass loading machine/glass lifting equipment

ass vacuum lifter /Vacuum lifters/Vacuum glass lifter / Vacuum glass lift

Detail product Description:

1. The vacuum glass lifter is for handling the glass sheet.

2. Voltage: Pump: 12V DC from rechargeable battery

                     Battery charger: 110V/240V 50HZ/60HZ, Single phase factory selectable

3. Glass lifter max. carrying capacity up to 650kg.( a safety factor 4.0 include)

4. The vacuum pump, valve, switch and some important spare parts we are import from oversea.

5. Stable performance, Easy to maintain, Efficient, safe, quick, easy.

6. The material of suction pad is NBR (oil resistance,skid resistance, corrosion resistance) , Be able to effectively and steel vacuum suction and produce vacuum.

6. The suction pad can be adjustablem, can be turned off and open individuallly.

7. The vacuum lifter is equipped with a buzzer and warning light units, in case of a power failure or vacuum leakage, an optical and an acoustic signal goes off immediately to warn the operator to do emergency operation.

8. The vacuum lifter is equipped with safety tank&Pressure switch warning, when the power is turned off in sudden, always can keep the workpiece not falling down for 15 minutes.

9. The design of vacuum lifter by our company is passed to EU CE 13155 passed.
It is CE identification Product.

10. There are 4 extension arms, numbers of 8 suction pads, dia. 300mm, each suction pad is moveable on the beam, each suction pad can turn off by individual ball valve, each extension arms can take off,  if the clients want to handling the glass sheet is small. which can ensure a same equipment can handling the different sizes glass sheet.

Application:

For Glass Production,

Glass Curtain Wall,

Glass Loading/Unloading,

Outdoor Mounting.

The glass lifter can be combined and operated with many different carrier facilities,such as crane,excavatos, wheel loaders, fork lifts.

Load Movement:

      Manual rotation, 360° edgewise, with locking at each quarter point

      Manual tilt, 90° between upright and flat, with automatic latching in upright position

Every product has passed at least six times inspection before shipping to our customers,like material incoming inspection, fist piece inspection,hardness and color inspection, QA inspection, Out-going inspection,etc

 Object pics:
