Shandong, Qingdao Stationary Electric Concrete Pump

FOB Price

US$ 30,000 - 58,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Power Type	Diesel
Place of Origin	Shandong, China	Brand Name	Xinxing
Model Number	HBT	Power(W)	75KW
Weight	5200KG	Dimension(LWH)	340013201480
Certification	ISO CE	Warranty	One Year
After-sales Service Provided	No overseas service provided

Shandong, qingdao Stationary Electric Concrete Pump

Description:

The concrete pump adopt electrical control reversing system and fully hydraulic, with

outstanding performances.

The hydraulic system has greatly improved the reliability of the whole machine to

guarantee safety of the machine under tough condition.

Our mainly typies of motor / diesel engine concrete pumps are with the

delivery capacity 15-120m²/h and delivery pressure 5-20Mpa.

Specification:

Item	Unit				S valve pump
					HBTS60-9
Theoretical concrete conveying amount	Low pressure	m³/h		60
	High pressure	m³/h		36
Theoretical concrete conveying pressure	Low pressure	Mpa		5.7
	High pressure	Mpa		9
Hydraulic system pressure	Mpa				26
Motor speed	r/min				1480
Main oil pump	Imported German HAWE / Japanese Kwasaki with original packing
Main oil cylinder diameter	mm				125/80x1650
Conveying cylinder diameter	mm				200
Motor power	Kw				75
Hydraulic oil tank capacity	L				500
Bucket capacity	m3				0.6
Work voltage	V				380AC
Whole machine weight			kg		5000
Maximum conveying distance	Perpendicular height		m		150
	Horizontal distance		m		600
