Variable area flow meter
- 500 Set / Sets per Month
- Shanghai
You May Like
Product Description
Specifications
Variable area flow meter1>Hi-accuracy popularly:1.0%,Special calibrated:0.5%
2>Output:4-20mADC
3>Display:pointer,LED
Variable area flow meter
Feature:
1.Low pressure loss
2.Hi-accutacy popularly:±1.0%,Special calibrated:±0.5%.
3.Low velocity min.velocity of flow:less than1.5m/s
4.Compensation with temperature and pressure compensation(option)
5.Lubricate with lubricated system(option)
6.LCD display
7.Multi output Pulse,4~20mADC
8.Spectum
15,25,40,50,80,100,150mm.
Specifition:
Model | Upper flow (m3/h) | Span | Error (%) | Pressure (mPa) | |
Water | Air | ||||
LZZ-15 LZD-15 | 0.025 | 0.7 | 10 | 1.5 ~ 2.5 | 1.6 *greater than1.6 |
0.04 | 1.1 | ||||
0.06 | 1.8 | ||||
0.1 | 2.8 | ||||
0.16 | 4 | ||||
0.25 | 7 | ||||
0.4 | 10 | ||||
LZZ-25 LZD-25 | 0.6 | 16 | |||
1 | 30 | ||||
1.6 | 45 | ||||
2.5 | 70 | ||||
LZZ-40 LZD-40 | 4 | 110 | |||
6 | 160 | ||||
LZZ-50 LZD-50 | 10 | 250 | |||
16 | 400 | ||||
LZZ-80 LZD-80 | 25 | 750 | |||
40 | 750 | ||||
LZZ-100 LZD-100 | 60 | 1800 | |||
60 | 2500 | ||||
LZZ-150 LZD-150 | 160 | 4000 | |||
NOTE: The model LZD with 4~20mA Output
Mark "*" means specital order
