400w 12/24V small wind turbine for home use/ marine use Quality Choice
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | NaiEr | |
| Model Number | NE-400 M3 | Type | Wind Power Generator |
Product Description
Small WInd turbine Details:
Wind turbine Features:
1.Low start up speed, 3 or 5 blades optional for different wind speed areas,high wind energy utilization
2.Easy installation, tube or flange connection optional
3.Blades using new art of precision injection molding , matched with optimized aerodynamic shape and structure,which enhance the wind energy utilization and annual output.
4.Body of casting aluminum alloy, with 2 bearings swivel , making it survive stronger wind and run more safely
5.Patented permanent magnet ac generator with special stator,effectively reduce torque, well match the wind wheel and generator, and ensure the performance of whole system.
6.Controller,inverter can be matched accroding to customers’ specific needs
Wind turbine Tech Data:
Model | NE-300M3 | NE-400M3 | NE-500M3 |
Rated power | 300W | 400W | 500W |
Maximun power | 330W | 430w | 530w |
Rated voltage | 12/24/48V | 12/24/48v | 12/24/48v |
Start-up wind turbine | 2.5m/s | 2.5m/s | 2.5m/s |
Rated wind speed | 10m/s | 10m/s | 10m/s |
Survival wind turbine | 45m/s | 45m/s | 45m/s |
Top net weight | 13kg | 13.5kg | 14kg |
Wheel diameter | 1.8m | 1.8m | 1.8m |
Number of blades | 3 | ||
Blades material | Nylon fiber | ||
generator | Three phase permanent magnet ac synchronous generator | ||
magnet | NdFeB | ||
Generator case | Casting aluminum alloy | ||
Control system | Electromagnet/wind wheel yaw | ||
Speed regulation | Automatically adjust windward direction | ||
Working temperature | -40°C - 80°C | ||
Design life | 20 y | ||
Gross weight | 16kg | ||
Package Dimension | 950x400x215mm | ||
Wind turbine power cruve:
For home use system, We offer you wind turbine + Controller+ Inverter+ battery+tower
