3kw horizontal wind generator for home use/ home turbine
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | NaiEr | |
| Model Number | NE-3000 | Type | Wind Power Generator |
Product Description
Specifications
1.home turbine is compact, safe and stable with low vibration2.high utilization with CE,
3.Easy installation and maintance
Home Turbine Features:
1.Casting aluminum alloy body, compact, little vibration
2.Excelent output,900w at 8m/s
3.Easy installation, tube or flange connection optional
4.Reinforced glass fiber blades,matched with optimized aerodynamic shape and structure,which enhance the wind energy utilization and annual output.
5.Tail adopts mechanical yaw technique, making it survive storm and run safely
6.Patented permanent magnet ac generator with special stator,effectively reduce torque, well match the wind wheel and generator, and ensure the performance of whole system.
7.Controller,inverter can be matched accroding to customers’ specific needs
Home turbine Tech Data:
Model | NE-3k | NE-5k | NE-10k |
Rated power | 3kw | 5kw | 10kw |
Maximun power | 4kw | 6kw | 13kw |
Rated voltage | 96/120/220V | 120/220/240v | 220/240/380v |
Start-up wind turbine | 3m/s | 3m/s | 3m/s |
Rated wind speed | 10m/s | 10m/s | 10m/s |
Survival wind turbine | 45m/s | 45m/s | 45m/s |
Top net weight | 205kg | 285kg | 400kg |
Wheel diameter | 5.6m | 6.3m | 8.2m |
Number of blades | 3 | ||
Blades material | Reinforced glass fiber | ||
generator | Three phase permanent magnet ac synchronous generator | ||
magnet | NdFeB | ||
Generator case | Carbon steel | ||
Control system | Electromagnet/wind wheel yaw | ||
Speed regulation | Tail furling | ||
Working temperature | -40°C - 80°C | ||
Design life | 20 y | ||
Home turbine Power Cruve
