Home > Products > Inner ring > Roller Bearings Type Inner Ring With Low Price LRT LRB Series
Roller Bearings Type Inner Ring With Low Price LRT LRB Series
- Shanghi/ Ningbo
You May Like
Product Details
| Brand Name | UBT | Bore Size | 5, 80 | |
| Outside Diameter | 8, 90 | Model Number | LRT LRB Series | |
| Number of Row | Single Row | Place of Origin | Anhui, China |
Product Description
Inner ring
The inner ring of IR series is quenched and made with high precision.The dimensional tolerance and the geometric precision of the standard grade inner ring is in compliance with P0 grade.In using FHL needle roller bearings,the selection of FHL inner ring will enable the bearing to keep a normal operational backlash.
shaft diameter | bearing designation | basic size | ||
d | F | B | ||
mm | mm | |||
| IR12X15X12 | 12 | 15 | 12 |
IR12X15X16 | 12 | 15 | 16 | |
IR/LR12X15X16.5 | 12 | 15 | 16.5 | |
IR/LR12X15X22.5 | 12 | 15 | 22.5 | |
IR12X16X12 | 12 | 16 | 12 | |
IR12X16X13 | 12 | 16 | 13 | |
IR12X16X14 | 12 | 16 | 14 | |
IR12X16X16 | 12 | 16 | 16 | |
14 | R14X17X17 | 14 | 17 | 17 |
| LR15X18X12.5 | 15 | 18 | 12.5 |
IR15X18X16 | 15 | 18 | 16 | |
IR15X18X16.5 | 15 | 18 | 16.5 | |
IR15X19X16 | 15 | 19 | 16 | |
IR15X19X20 | 15 | 19 | 20 | |
120 | IR120X130X30 | 120 | 130 | 30 |
IR120X135X45 | 120 | 135 | 45 | |
130 | IR120X145X35 | 130 | 145 | 35 |
IR130X150X50 | 130 | 150 | 50 | |
140 | IR140X155X35 | 140 | 155 | 35 |
IR140X160X50 | 140 | 160 | 50 | |
150 | IR150X165X40 | 150 | 165 | 40 |
Package and delivery
Certification
our mainly products are the following
1. Drawn Cup needle roller Bearing: HK, HK..(2)RS, BA, SCE, HMK, BK, B, F, FY, FH etc series.
2.trust roller bearing: AXK, AS, NTA, TC, TRA, TRB, TRC,TRD,K811TN, K812TN, AX series.
3.Heavy Duty needle roller bearing: NA, NK, NKI, NAV, NAO, HJ, BR, BRI etc.
4. Combine bearing: NKIA, NKIB, ZARN, ZARF, SL04, SL 18 etc series
5. roller and cage assemblies; KZK, KBK, K…ZW etc series.
6. inner ring: IR, LR etc series.
7.cam followers: KR, CF, NATR, NUTR, NUKR etc series.
8.clutches: HF, HFL, RC, RCB, CSK, TNS, TFS, DC etc series.
9.Bearing for Peugeot Car: DB68933. DB 68934, NE 70214, NE 70216 etc series.
