Electric Pressure Controller JH-1.1 Pressure Controller
- NINGBO/SHANGHAI
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Electronic Pressure Controller for Water Pump JH-1.2 Pressure Switch
-
Electric Pump Controller Panel JH-1.3
-
Self-priming Pump Automatic Pressure Control Switch for Water Pump (JH-1.3)
-
Automatic Pressure Switch for Water Pump JH-1.3 Pressure Flow Controller
-
Water Pump Pressure Control Switch JH-1.2 Water Flow Control Switch
-
Pump Pressure Switch Water Pressure Sensor JH-1.3 Pressure Controller
Product Details
| Place of Origin | Zhejiang, China | Brand Name | JIAHONG | |
| Model Number | JH-1.1(pressure control) | Max. Current | 10A | |
| Max. Voltage | 240V | Max. Working Pressure | 20bar |
Product Description
Pressure Controls JH-1.1
Description:
| Rated Voltage: | 110V–240V |
| Frequency: | 50/60Hz |
| Max. Current: | 10A |
| Max. Power: | 1.1KW; 1.5KW; 2.2KW |
| Starting Pressure: | 1.2bar; 1.5bar; 2.2bar |
| Max. Pressure: | 10bar |
| Connection Thread: | R1" |
| Protection Grade: | IP65 |
| Max. Operating Temperature: | 60 |
| Cable Specifications: | 7.5-9mm |
Function:
1. Automatic pressure switch used for drinking water or non-potable water
piping systems.
2. Replace the traditional system which assembled with pressure switch,
pressure tank and check valves.
3. Stop the pump automatically when water shortage.
4. It starts the pump automatically when pressure decrease (tap opening) and
stops it when there is no flow (tap closing).
Optional:
| Color: | blue; yellow; black |
| Starting pressure: | 1.2bar; 1.5bar; 2.2bar |
| Max. Power: | 1.1KW; 1.5KW; 2.2KW |
| Cable Specifications: | 7.5-9mm |
Possible Working Defects:
type of defect | causes depending on the unit | causes not depending on the unit |
-The pump does not start | -The electronic card is broken | -Voltage failure -Pump jammed -Electric cables inverted(line/motor) |
-The pump does not stop | -The electronic card is broken -The flow detector is blocked in the upper position -The reset button is blocked -The pump does not provide sufficient pressure | -Presence of leaks which are higher than the minimum flow 0.6L/min |
-Intermittent pump working | -The electronic card is broken -The pump does not provide sufficient pressure | -Presence of leaks which are lower than the minimum flow 0.6L/min |
-The pump is jammed | -The electronic card is broken -The pump provides a pressure which is lower than the restarting pressure | -Water failure -Suction problems |
