Automatic Stand-up Pouch Packaging Machine
- QINGDAO
- T/T D/P D/A
You May Like
Product Details
| Condition | New | Application | Chemical, Food, Other, Medical, Chemical, Food, Machinery & Hardware, Medical, Doypack/Horizontal Stand-up Pouch Packing Machine | |
| Packaging Type | Other, Doypack/Horizontal Stand-up Pouch Packing Machine | Packaging Material | Paper, Plastic | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | AC380v,50hz | Power | 5.5kw | |
| Place of Origin | Shandong, China | Brand Name | DARIN | |
| Model Number | LSU-220/350 | Weight | 1000kg | |
| Dimension(L*W*H) | 2950 x 980 x 1450mm | Certification | CE&ISO9001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Introduction
Stand-up Pouches Packaging Machine can use premade pouch for packing all kinds of materials or products.
Machine type: horizontal or vertical type
Product could be packed: liquid, solid/granules, powder
Certificate
CE Certificate, ISO9001 Certificate
/watch?v=DCKHQi7F4eA
/watch?v=u23jMoA6Xkg
Features
1. Adopt import AC motor and frequency control of motor speed, run stably.
2. Using heat sealing packing materials, the machine can complete the procedures of conveying product, weighing, conveying bags, open bags, filling product, sealing, conveying final packages continuously and automatically.
3. Different product could be packed by choosing different filling machine.
4. Composed by PLC, touch screen, VVVF, etc, has high integrated level and control ability.
5. Photoelectric sensor, encoder and close switches are all adopt advanced sensing element.
6. Suitable to use flat bag, stand bag, zipper bag, wide-bottom bag, etc.
Technical Parameters
Model | LSU-220D | LSU-350D | |
Bag length | 120-350mm | 150-380mm | |
Bag width | 95-200mm | 150-250mm | |
Packing speed | 25-45bag/min | 25-45bag/min | |
Packing weight | Max 1kg | Max 1kg | |
Power | 5.5kw | 5.5kw | |
Air compressor | 0.6cbm | 0.6cbm | |
Suitable bag type | Flat bag, stand-up bag, zipper bag | Flat bag, stand-up bag, zipper bag | |
