Servo Vertical plastic molding machine XT-VD120
- 2000 Set / Sets per Month
- NINGBO
- T/T Credit Card
You May Like
-
PVC flexible uppers vertical injection machine
-
60 ton servo vertical injection moulding machine with rotary table
-
Xiangte plastic injection machinery in competive price
-
Xiangte plastic injection machinery in competive price
-
ISO certificated vertical plastic injection machinery
-
100T Vertical Plastic Injection Machine for Shoe Soles
Product Details
| Condition | New | Type | Tube Shoulder Injection | |
| Style | Vertical | Brand Name | XT | |
| Model Number | XT-VD120 | Place of Origin | Hebei, China | |
| Plastic Type | Thermoplastic | Automatic | Yes | |
| Injection Weight | 300-460CM3 | Injection Rate | 150G/S | |
| Clamping Force | 1200KN | Opening Stroke | 320MM | |
| Power(W) | standard | Certification | CE/ISO | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Servo Vertical plastic molding machine XT-VD1201.Clamping force:1200kn
2.Injection weight:400g
3.Machine weight:3t
1.What products our machines can make
2.Main technical data
Technical Parameters | ||
Injection Device |
|
|
| UNIT | DATA |
SCREW MODEL |
| STANDARD |
SCREW DIAMETER | MM | 50 |
INJECTION PRESSURE | Mpa | 115 |
THEORETICAL SHOT VOLUME | CM³ | 390 |
SHOT WEIGHT(PS) | G | 315 |
INJECTION RATE(PS) | G/S | 150 |
SCREW SPED | R/PM | 6-300 |
Clamping Device |
|
|
CLAMPING MODEL |
| INVOLUTION |
CLAMPING FORCE | KN | 1200 |
MAX. PLATE STROKE | MM | 320 |
MOULD THICKNESS | MM | 150-400 |
SPACE BETWEEN TIE-BARS(HxV) | MM | 440x340 |
MOULD PLATE SIZE(HxV) | MM | 610x510 |
EJECTOR FORCE/STROKE | KN/MM | 45/70 |
Others |
|
|
MOTOR POWER | KW | 11 |
HEATING POWER | KW | 8.5 |
MACHINE WEIGHT | TON | 2.7 |
MACHINE SIZE(LxWxH) | M | 1.72x0.94x2.85 |
3.About our company
Hebei Xiangte Imp.& Exp. Co.,ltd is a exclusive sales agent of Hebei Xiangte Plastic Injection Machinery Co.,ltd. Established in 1999, Hebei Xiangte Plastic Injection Machinery Co.,ltd is specialized in the research, manufacturing, sales and service of various plastic molding machines. With many years experience of professional techniques and sales network, we can provide customers with high-tech, high-precise and high -speed injection molding machines. .Depending on competitive price, top services and perfect quality, our products have been exported to over 60 countries in Asia, East Europe, Africa and South America. We hope you to visit our factory.
4.Main parts
