Horse Trailer Ramp - 3HAL

Specifications

 Horse Trailer Ramp - 3 Horse Angle Load Float -Deluxe

• chassis material  double galvanized RHS(3.5mm-4.0mm)
• frame material  double  galvanized RHS(2.5mm)
• body panel  galvanized (1.2mm)
• roof   special molded FRP  5155*1980
• wheel rim  14' aluminium alloy rims
• tyres  185R14C
• spare wheel  one
• axles  two special trailer axles
• leaf springs  tandem spring suspension 9 plates
• brake system  double axle electric brake
• front window  Tinted front  windows 1220*610
• side window  three sliding windows on each side
• vents  two pop-up vents
• rear upper door  2020*1065
• ramp door  2020*1210
• rear upper & ramp door strut  high-intensity anti-rust strut
• drawbar checker plate  1.2mm aluminium
• drawbar safety chain two
• bracing wheel  one
• trailer plugs  square 7 wick plug
• side lamps  6
• rear lamps  LED group
• rear lamps stand  aluminum
• petro reflectors  10
• mudguard checker plate  1.2mm aluminium in the front of mudguard
• pedal& aluminium step  1.2mm aluminium decoration board
• cupboard  front cupboard
• fridge  a 50L fridge
• microwave  one microwave
• horse protection frame  full padded
• tie up ring  four
• rubber matting for ramp door  10mm rubber matting
• rubber matting for floor  10mm rubber matting
• rubber matting for inner side panel  5mm rubber matting
• wood board for floor & ramp door  18mm hardwood plywood
• rug rack full length side
• tack box  none
• saddle rack  in the saddle box
• saddle box  aluminium
• painting  single or multi-color
• overall dimensions( L x W x H: mm )  6025*2280*2590
• body dimensions ( L x W x H: mm )  5155*1980*2230
• inner dimensions ( L x W x H: mm )  5025*1930*2155
