Semi-automatic Carton Stitching Machine
- TianJin
- T/T
You May Like
-
Corrugated Carton Box Stapler Stitching Machine
-
Hot Sell Carton Box Nailing Stitching Machine From China Manufacturer
-
Cardboard Box Manual Stitching Machinery/Manual Nails Packing Machine/Nails Box Packing Machine
-
Flat Iron Wire Box Stitching Machine , Carton Box Nailing Machine
-
DX-1400 Carton Stapler--Corrugated Nail Box Machine, Spike Nail Machine Nail Stamping Machine, Stapler
-
DX-1200 Carton Stapler--Corrugated Nail Box Machine, Spike Nail Machine Nail Stamping Machine, Stapler
Product Details
| Condition | New | Application | Apparel, Other, Apparel, Machinery & Hardware | |
| Packaging Type | Film | Packaging Material | Plastic, Wood | |
| Automatic Grade | Automatic | Driven Type | Electric | |
| Voltage | 380V 50Hz | Power | 2.2KW | |
| Place of Origin | Hebei, China | Brand Name | XH | |
| Model Number | JHHW | Dimension(L*W*H) | 3300*2500*2000 | |
| Weight | 1T | Certification | CE and ISO certificates | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
semi-auto stiching machine/ corrugated box stappler machine
1 Single ,double and strengthened nail are available
2 Nailing from 30-120 mm , auto-calculated; serive motor controls the nailing from by Delta, Japan.
3 5.7 in Hd color touch screen by Eview, Taiwan
4 PLC system and electrical devices by Siemens, Germany; phtoto-electricity switch and limit switch by autonics, Korea, high quality assured; the motor and reducer are made in Taiwan.
5 The reamer of pinhead is made by tungsten steel of Germany. Maching is exactitude by special heat – treatment and numerical control system .
6 All of the bearing are made by Brand of Germany
7 Full electrical controlled and it can be changed the size in one minute and handle easily without the relevant experience .
8 Nailing speed : 400nails /min
9 Number of Nails: 1-99
10 Automatic counter in the latter part ; deliver paper boxes in lot as set for strapping .
11 Total power : 6kw
12 paper height : 900 mm
13 Demensions:3300×2500×2000 mm
14 For Cardboard : 3/5layers corrugated paper
15 Wire size: 17# flat Yam (2.0×0.75)
Main specifications :
Maximum board size | 2800×1515 mm | Nailing speed | 400 nails/min |
Minimum board size | 550 ×300 mm | Total power | 5 kw |
Paper height | 900 mm | Number of nails | 1-99 |
Nailing form | 30-120 mm | Diemensions | 3300×2500×2000 |
