Copper/PVC/SWA/PVC PVC Steel Wire Armoured Cable Power Cab;e

0.6/1kV PVC insulated Armour powercables:

Copper/PVC/SWA/PVC PVC steel wire armoured cable(swa) can endure mechanical force

PVC/XLPE insulation armour electric cable, CU/AL conductor, PVC/XLPE insulated, PVC/PE sheathed, Steel armoured, OEM offered

1. Standard:

IEC, ASTM, BS, CNS(GB), DIN and AS/NZS or other standards as request.

2. Rated Voltage:

0.6/1KV

3. Construction:

Conductor: Copper or Aluminium
Insulation: PVC or XLPE
Inner sheath: PVC
Armoured: Galvanized steel tape or galvanized steel wire
Outer Sheath: PVC or PE

4. Characters:

A. Max Long-time operating temperature of PVC insulated cable is 70° C, XLPE 90° C
B. Installing temperature of cable should not be less than 0° C
C. Max short-circuit temperature is: PVC not exceed 160° C, XLPE 250° C, Not more than5 Sec.
D. Permitting bending radius cable: Not less than 10 D times (D: External diameter of cable)
E. Perfect chemical stability, resistant against acids, alkalis, grease and organic solvents, and flamer retardant.

5. Application:

Medium Voltage Power Cable is used in fixed laying to
Distribute the electricity in the AC rated voltage 35kV and under 35kV transmission line.

Wooden Drum Package or Iron-wooden drum

7. Nominal cross-sectional areas:

1.5 mm2, 2.5 mm2, 4 mm2, 6 mm2, 10 mm2, 16 mm2, 25 mm2, 35 mm2, 50 mm2, 70 mm2, 95 mm2, 120 mm2, 150 mm2, 185 mm2, 240 mm2, 300 mm2 400 mm2 500 mm2 630 mm2 800 mm2

8. Production range:
Single core cable from 1.5 mm2 to 800 mm2, muli-core cable from 1.5 mm2 to 400 mm2

Type and Data

Cable Structure

Established Year: 2014
Registered capital of RMB:100,000,000
Factory Area:36,000m2
Manufacturing Capacity per year: 250000km
Number of Employees: 250

Main products:
Bare conductors(AAC,ACSR,AAAC,ACAR,Aluminum Clad Steel Conductor);

Aerial Bundled Cable (ABC Cable);

Power cable,Electrical wire cable,

Armored cables,

Control cables,

Rubber insulated cables, PVC insulated wires and cables,

Battery cables,Instrument cables, Coaxial cables,Flat cables,

Welding cables,House wire,Special Cables etc.

1.Q: Is your company a manufacturer or a trade company?

A: We are cable manufacturer.

2. Q: Where is your factory located? How can I visit there?
A:Our factory is located in Ningjin City, Hebei,Province, China. You can fly to Shijiazhuang airport directly. All our clients, from home or abroad, are warmly welcome to visit us!

3. Q: What is your sample policy?

A: Some of our samples are available for free, while others are available at a cost, which will be deducted from the purchase order.

4.Q: How does your factory do regarding quality control?

A: Quality is priority. We always attach great importance to quality controlling from the very beginning to the very end.

5. Q: I am very interested in your product, can you sent me your full catalog and pricing list?

A: We can select some popular products for you immediately.  Please let us know your requirements so that we can send out the quotation to you.
