0.6|1kv Low Voltage Power Cable

CU Conductor XLPE Insulated PVC Sheathed Power Cable

1.The applications: Rated voltage (U0/U) 0.6/1kv  8.7/15KV  26/35kV in transmission & transformation line & for water-proofing purpose .

2. Cores: 1~5 cores,3C+1E,4C+1E,3C+2E

3.Standards: 60502IEC  ISO9001

4. Product features:

1) No necessary to heat up in advance while installing above 0oC.

2) Max. continuous normal operating Temperature: 90oC (PVC Sheathed cable).

3) Max. Permissible temperature at short circuit (5s. at longest): 250oC.

4) Permissible bending radius:

Single core: ≥20(d+D)±5%.

Three-core:≥15(d+D)±5%(D is the actual overall diameter of cable, and d is the actual overall diameter of conductor).

Model and Data

Our Products

YITENG COMPANY

Yiteng Cable Technology Hebei Co., Ltd
Established Year: 2014
Registered capital of RMB:100,000,000
Factory Area:36,000m2
Manufacturing Capacity per year: 250000km
Number of Employees: 250

Main products:

Bare conductors(AAC,ACSR,AAAC,ACAR,Aluminum Clad Steel Conductor);

Aerial Bundled Cable (ABC Cable);

Power cable,Electrical wire cable,

Armored cables,

Control cables,

Rubber insulated cables, PVC insulated wires and cables,

Battery cables,Instrument cables, Coaxial cables,Flat cables,

Welding cables,House wire,Special Cables etc.

FAQ:

1.Q: Is your company a manufacturer or a trade company?
A: We are cable manufacturer.

2. Q: Where is your factory located? How can I visit there?
A:Our factory is located in Ningjin City, Hebei,Province, China. You can fly to Shijiazhuang airport directly. All our clients, from home or abroad, are warmly welcome to visit us!

3. Q: What is your sample policy?

A: Some of our samples are available for free, while others are available at a cost, which will be deducted from the purchase order.

4. Q: I am very interested in your product, can you sent me your full catalog and pricing list?

A: We can select some popular products for you immediately.  Please let us know your requirements so that we can send out the quotation to you.
