Square Vacuum Dryer
- SHAGNHAI
- T/T
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Jinbao | |
| Model Number | JB |
Product Description
Main Usage
Suitable to the materials-drying for the lines of medicine , chemical , foodstuff, and electronics.
Specialty
1 Under constant temperature if the vacuity of drum is improved ,the drying speed can be shortened.
2 Under constant vacuity if the heating temperature is elevated ,it can accelerate the drying speed .
3 If both the vacuity and heating temperature is elevated ,the drying speed can be shortened greatly .
If a condenser is accepted , the vaporized agent in the target materials can be recollected by condenser , which is the normal drying facility ,If Model JZJS-70 liquid loop pump vacuum unit is Used , the condenser can be omitted to save energy and investment .
Technical Data
Model | YZG-600 | YZG-1000 | YZG-1400 | FZG-15 |
Inner size of drying box (mm | Φ600×976 | Φ1000×1527 | Φ1400×2054 | 1500×1400×1220 |
Outer size of drying box (mm) | 1135×810×1020 | 1693×1190×1500 | 2386×1675×1920 | 1513×1924×2060 |
layer of dry rack | 4 | 6 | 8 | 8 |
Distance between layers (mm) | 81 | 102 | 102 | 122 |
Size of dry tray (mm) | 310×600×45 | 250×410×45 | 400×600×45 | 480×630×45 |
Number of dry tray | 4 | 24 | 32 | 32 |
Use press.inside of pipe (Mpa) | ≤0.784 | |||
Use temperature of rack () | -35150 | |||
No load vacuum inside box (Pa) | 1330(10mmHg) | |||
