Tact Switch &Miniature Type Digital Camera Push Bottom Tact Switch
- ShenZhen
- T/T
You May Like
-
Miniature Type Digital Camera Push Bottom Tact Switch
-
Tact Switch &Miniature Type Digital Camera Push Bottom Tact Switch
-
Tact Switch &Miniature Type Digital Camera Push Bottom Tact Switch
-
Tact Switch &Miniature Type Digital Camera Push Bottom Tact Switch
-
Tact Switch &Miniature Type Digital Camera Push Bottom Tact Switch
-
6*6 Tact Switch &SMD Tact Switch Series
Product Details
| Place of Origin | Guangdong, China | Brand Name | Ganhad | |
| Model Number | IT-1503 | Max. Current | 12V | |
| Max. Voltage | 50mA |
Product Description
Specifications
1, Improve mounting density components on PC board2, Reflow solderable
3, Contacts are completely sealed, enhancing reliabi
Specification:
Temperature: -30°C to +85°C
Rated Load: DC12V 50mA
Cotact Resistance: ≤ 50m Ω
Inslation Resistance: ≥ 100mΩ
Withtand Voltage: AC250V (50Hz)/min
Life: 100000cycles
Application of TACT switch series
Widely apply to:
1.Audio Products:MP3,MP4,DVD. Audio;
2.Digital Products:digital camera,digital video and so on;
3.Remote Control:the remote control of automobile domestic security products; 4.Communication Products:mobile phone,vehicle-mounted phone,telephone set,building equipment,PDA and so on;
5.Homehole appliances:TV set,microwave oven,electric rice cooker,electric fans and so on; 6.Security Products:visual interphone,monitor and so on;
7.Toys:electric toys and so on;
8.Computer Products:PC camera and so on;
9.Exercises Machines:treadmills,massage armchair and so on;
10.Medical Device:sphygmomanometer,thermometer,hospital call system and so on;
11.Others:Counterfeit Money Defector Pen,laser pen and so on;
