Rectifier 24V 3000A

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Germany	Brand Name	Mak Plus Power Systems
Model Number	REC-MAK 24_3000	Type	Other, Rectifier
Application	Inverter / Converter	Package Type	Other, Normal
Peak Repetitive Reverse Voltage	400V or 230V

Rectifier for Electroplating
24V 3000A Rectifier
Galvanizing
Electroplating
Oil or Water or Air Cooled

REC-MAK Series Rectifier Solutions 24V – 3000A http://www.mak-powersis.de/24v-rectifier.html
Input	Power kVA	83kVA
	Voltage	230V – 380V – 400V – 415V 480V AC / 50Hz – 60Hz 3 Phase + N
	Current	60A (Phase)
	Harmonics	>%7


Output	Power kVA	72kW
	Voltage	12VDC (0.1V Adjust)
	Current	3000A
	Efficiency	Minimum %85
	Ripple	<%4 (Optional Less)


Control	Technologie	Thyristor Technology
	CPU	Micro Controller Texas Instruments
	Pulse	6 Pulse & (12 Pulse or Switch Mode Optional)


GENERAL	Color	RAL7032
	Transformer	Copper
	Timer	Exists Adjustable Working Time
	External Stop	Standard
	Input Protection	Thermionic Magnetic Circuit Breaker
	Over Current Protection	MCCB & Software
	Parallel Operation	Optional
	Dry Contacts	Optional
	Cooling Type	Air Cooled or Oil Cooled
	Remote Controller	50 Meter (Optional)
	Communication	SNMP, RS232, RS485, USB, MODBUS (Optional)
	Working Temperature	0C / +40C Celcius – Batterien 0C – 25C
	Protection Additional	Standard Information
	Over Current Protection	Via Software
	Voice (1m)	<65Db
	LCD	LCD Screen with buttons
	Cooling Power	Max 43000
	Standard Protection	EN 62040-1
	Standard EMC	EN 62040-2
	Working Altitude	2200 Meter


Chassis	Width mm	2200
	Depth mm	1500
	Height mm	1800
	Weight kg	2880kg
	Protection Class	IP20 or optionalOutdoor IP21, IP22, IP42, IP55, IP65
