Roof Mounted Freezer Truck Refrigeration
- Tianjin / Tsingtao / Shanghai
 - T/T

You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | thermokingtec | |
| Model Number | TKT-200EF |
Product Description
roof mounted freezer truck refrigeration
TKT-200EF (Battery Driven)
Roof Top Model
TKT-200EF is specialized for small cargo van to keep frozen. It is powered by the battery of the vehicle, and has great advantages in environmental and highly efficient.
s Designed for Cargo Van Up to 19CBM(0 °C) & 7CBM(-20°C) to Keep Frozen;
s Easy Installation & Operation;
s Low Current, Long Time Running & High-Low Voltage Protection;
s Environment Friendly;
s 36 Months Warranty Time After Installation;
Technological data of roof mounted freezer truck refrigeration:
TECHNICAL DATA  | |||
NO.  | Items  | Data  | |
1  | Product Name  | Van Refrigeration --TKT-200EF  | |
2  | Type  | Battery Driven Compressor Complete Electrical Refrigeration System  | |
3  | Structure  | Roof Top Model / Cargo Van/Truck Body, Roof Top Installation  | |
4  | Compressor  | Electrical Compressor, 36CC/R  | |
5  | Controller  | Digital, In Cab  | |
6  | Condenser  | Coil  | Copper Tube & Aluminum Fin  |
Fan  | One Motor & One Fan (DC12V/24V)  | ||
Dimension  | 865*700*185MM  | ||
  | Battery Driven Compressor Inside  | ||
Weight  | 50KG  | ||
7  | Evaporator  | Coil  | Copper Tube & Aluminum Fin  |
Fan  | One Motor & One Fan (DC12V/24V)  | ||
Air Flow  | 995 m3/h  | ||
Dimension  | 600*510*138 mm  | ||
Weight  | 17KG  | ||
8  | Defrost  | Automatic Hot Gas Defrost  | |
9  | Refrigerant  | R404A, 1.1-1.2KG  | |
10  | Current  | 12V DC—60A / 24V DC--30A  | |
11  | Installation Kits  | Rubber Hoses, Drain Water Hoses, Wiring Harness Etc  | |
12  | Cooling Capacity (Ambient 38Deg/100.4F)  | -20Deg--1250 W (4265 BTU/ 1075 Kcal ), Apply Up to 7 m3, Frozen & Fresh  | |
0Deg---2800 W(9553 BTU / 2410 Kcal ), Apply Up to 19 m3,Fresh  | |||
13  | Total Weight  | 75KG  | |
14  | Recommend 4*100A.H Battery, Van Body Insulation Thickness 75mm-100mm  | ||
Optional: 110V/220V/380V Stand By Units is Acceptable;  | |||
Photos of roof mounted freezer truck refrigeration:

Pre-sale:
(1) Professional suggestions (model selection ,technical solution , installation training…)
(2) Device model choice (recommend the best product according to vehicle model, temperature
rating, the container volume…)
(3) 24 hours service.
(4) Welcome to visit our factory and production line anytime.
(5) Introduce the company file, product categories and production process.
Sale:
(1) Update the production scheduling in time.
(2) Quality supervision.
(3) Product acceptance.
(4) Shipping on time.
After-sale:
(1) Installation guide for free.
(2) within the warranty period: spare parts are provide freely.
(3) Technical support the whole using life.
In China, we have been manufacturing high quality products as an OEM to Yutong Bus and CIMC
company since 1998. We are the most influential manufacturer of bus and refrigerated truck in
China. Until now, our products have begun to be introduced to 65 countries in Europe, Asia,
North America, South America and Africa, earning high reputation and sustainable growth in all
markets.
Q:Why choose our product?
A:TKT, as the first and leading manufacturer of bus air conditioner and truck refrigeration in
China, has devoted to producing reliable, efficient and economical bus air conditioner and
truck refrigeration for the world.
Q:What are your products certified ?
A:All products have CE and ISO9001:2008 identification.
Q:How about installation training?
A:Professional engineers training can be offered.
Q:How long is your products warranty?
A:36 months warranty is available.
Q:How many countries have your products been exported to?
A:Until now, our products have begun to be introduced to 65 countries in Europe, Asia, North
America, South America and Africa, earning high reputation and sustainable growth in all
markets.
