reactive power auto compensation controller
- NINGBO PORT
- T/T
You May Like
-
JKW5C controller automatic reactive power compensation controller
-
JKW5C Auto Compensation Controller
-
High quality RPCF3 series automatic phase discriminated reactive power compensating controller
-
High quality RPCF3 series automatic phase discriminated reactive power compensating controller
-
High quality RPCF3 series reactive power compensating controller
-
High quality RPCF3 series reactive power compensating controller
Product Details
| Place of Origin | Zhejiang, China | Brand Name | JKCN | |
| Model Number | JKW58 |
Product Description
Specifications
1.High power factor measurement accuracy2.Wide display range
3. AC380V
4. 138*138MM
5. 2/4/6/8/10/12steps
General Description
The reactive power auto- compensation controller is the auxiliary product for low voltage capacitor screen. According to the different
demands of user, the company developed successfully the JKL5C, JKW58, RRCF, JKW9F, JKW5C types of intelligent controller series;
Number of the channels controlled is 4,6,8,10 and 12 available. All of these devices are controlled by the microcomputer, with the advanced
technology, they have complete range of functions, rather strong anti-interference ability, stable and reliable operation, accurate compensation
and novel appearance, so they are the preferred products of capacitor screen manufactuers
Main Technical parameter
Items | JKW5C | JKG2B | JBL | JKW58 |
Rated working voltage | 380V±20%, 50Hz | 220V±10%, 50Hz | 220V±10%, 50Hz | 380V±20%, 50Hz |
Sampled input current | AC, Iin≤5A | AC, Iin≤5A | AC, Iin≤5A | AC, Iin≤5A |
Output contact capacity | 220V×5A, 380V×3A | 220V×5A, 380V×3A | 220V×5A, 380V×3A | 220V×5A, 380V×3A |
Dielectric strength | AC3000V | AC3000V | AC4000V | AC3000V |
Working method | Continuous | Continuous | Continuous | Continuous |
Switch on threshold | Reactive current >1.1Ic, cosφ<cosφ preset |
Cosφ<0.93 |
Cosφ<0.93 | Reactive current >1.1Ic, cosφ<cosφ preset |
Switch off threshold | power factor>Cosφ preset |
Cosφ<0.98 |
Cosφ<0.98 | power factor>Cosφ preset |
Swtiching time delay | 5-100s adjustable | 5-100s adjustable | 40s | 5-100s adjustable |
Over voltage protection | 400-450v adjustable | 230-250v adjustable | 230-250v adjustable | 400-450v adjustable |
Phase sequence of sampling singal |
Automatic identifying |
Automatic identifying |
|
Automatic identifying |
Self-checking function | Yes | Yes | Yes | Yes |
Channels controlled | 4,6,8,10,12 | 4,6,8,10,12 | 4,6,8,10 | 4,6,8,10,12 |
Overall wattage dissipation | 10W | 15W | 10W | 10W |
Overall Weight | 1.35kg | 1.8kg | 1.00kg | 1.35kg |
Size of mounting hole | 113×113mm | 162×102mm | 138×138mm | 138×138mm |
Q 1. How's the delivery time ?
A. Depend on your quantity ,usually within 15days after receive your payment in advance.
Q 2.Would you accept to use our logo ?
A. If you have good quantity,it absolute no problem to do OEM.
Q3. Would you offer free sample?
A. We will offer you free sample for the motor capacitors. for power capacitor will not be free.
Q4 What's your guaranty time?
A. One year,if mmet quality problem duing this time, we will take charge of it.
Q5 What's your payment term?
A. TT LC West Union.
Q6 What's the rated working voltage of your controller?
A. 220V,380V.
Q7 Do you have the function of self-checking ?
A. Yes.
Q8 What's the size of mounting hole ?
A. 113*113mm, 162*102mm,139*139mm
