Product Details

Place of Origin	Guangdong, China		Brand Name	Pure-Air
Model Number	PA-300TS(Single Inlet) &PA-300TD(Double Inlet)		After-sales Service Provided	Overseas third-party support available

Product Description

Specifications

PA-300TS/TD air filtration used on laser medical work to filtrate the smoke, smells and toxic gas.

PA-300TS/TD protable Laser medical work air filtration

1. Strict welding and painting technology achieve to high tightness and corrosion resistance cabinet.

2. Specific sound-absorbing materials reduce operating noise to improve operation efficiency.

3. Taiwan brushless blower, new high pressure technology, small size, brushless design & electronic speed adjustment. It can effectively absorb particle and extend filter life of less power.

4. PWM speed control, according to the amount of dust to achieve precise adjustment.

5. By the pre-filter, HEPA main filter and the chemical gas filter composed of three parts filtration system. The main filter and gas filter package blocked with the metal net, it can effective remove fume and harmful gases in the air to achieve indoor air quality restoration. Also reduce the equipment size, saving floor space.

6. After multi-stage dust filtration, can be directly emitted in the room without expensive & complex exhaust project.

7. The indoor temperature can be stability, and save energy. There is no indoor negative pressure to maintaining the air cleanliness.

8. Fliter Data

Filter Elements Data
Item	Technical Data	Remark
Pre-filter	G4 class, life-time 1-3 months	Cotton filter pad
Main-filter	H14 class HEPA, life-time 6-10 months	Filter can remove 99.997% of all particles above 0.3 microns and 95% down to 0.01 micron.
Air-filter	Chemical material, life-time 6-10 months	Chemical molecular, Oxidant & Active carbon adsorb noxious gas.
Average filtration rate	≥99.7%	It will be a little fluctuation according to different materials.

9. Technical Paremeters

Blower Technical Data
Item	Technical Data	Remark
Running period	more than 30,000h	One year guarantee
Max. air flow	300m³/h	Electronic speed control
Input capacity	130W	Low capacity
Air pressure	2500pa	High pressure
Running sound	≤45dBA	Low sound volume
Input power	110/220V, 50Hz/60Hz	International standard

Equipment Data
Item	Technical Data	Remark
Fume & dust inlet	50mm	Single/double fume inlets, include one/two set fume extract tube
Fresh air outlet	100mm	Shutter
Machine weight	15KG(N.W.)	Machine with all elements
Dimension	310×330×450mm	Machine size
Package dimension	405×410×480mm	Packed by plywood crate
