Timber Beam Manufacture

FOB Price

US$ 7 - 8 / Meter

500 Meters(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China		Brand Name	LUOWEN
Model Number	LW-TB103

Characteristics:

1,Light Weight: the density of H20 Timber Beam is only 4.8-5.0 kg per meter, it is easy to deliver,dismantle and install.

2,High Tenacity: The H20 Timber Beam is not easy to break off because of fiber.

3,Good Proofing: The H20 Timber Beam is good at waterproofing, acidproofing, alkali proofing, moth proofing.

4,Environment Friendly: The Timber Beam belongs to renewable resources, could be used many time.and without poison, no damage to health.

5,Good Straightness: The H20 Timber Beam in not easy to deform.

Specifications
Item	LW-TB103
Wing Material	Imported spruce solid wood, finger-jointed and glueing according to DIN 68140-1
Web Material	Multilayer poplar plywood
Head Protection	Injection molding plastic head
Glueing	(PRF) Finger-jointed between wings and web pursuant to approval notice Z-9.1-146
Moisture Content	less than 12% at the time of delivery
Surface Protection	The complete beam is waterproofed using a water-repellent color glaze
Color	Yellow or as customer's request
Wing Size	80x40mm
Web Size	30mm thickness
Weight	about 5kg/m
Standard lengths	2.45 / 2.90 / 3.30 / 3.90 / 4.90 / 5.90 m (Max.length:6.00m)
Mechanical Specification	Modulus of elasticity : E 11,000 N/mm2
Mechanical Specification	Shear modulus : G 600 N/mm2
Packing	Pallet or in bulk
Application	Level formwork system, Vertical formwork system, Adjustable formwork system, Curve formwork system, Irregular formwork, etc.

....
