high quality HDG frame scaffolding
USD $1,000 - $1,400
/ Ton
20 Tons(Min.Order)
- 4000 Ton / Tons per Month
- NINGBO SHANGHAI
- T/T L/C D/P D/A Credit Card
You May Like
-
high grade ringlock scaffolding system Steel Ringlock Scaffold
Quality Choice
-
High Quality Mobile Tower Used Aluminum Scaffolding for Construction
-
hotsale! FRAME scaffold
-
High Grade Steel Cuplock Scaffolding for Construction
-
used cuplock scaffolding for sale
-
Light Weight Aluminium Scaffolding for Construction
Product Details
| Place of Origin | Zhejiang, China | Brand Name | LW |
Product Description
Frame System
Character:
- Simple structure: The main parts include the frame ,catwalk, cross brace, it is easy to assemble and disassemble, and also easy to storage, transfer and maintain.
- High loading: The standard actuates axially, this makes the scaffolding in the three-dimensional space, high strength and steady of the structure. The cross plate is good at axial shearing resistant, and makes the axis of each pipe in one plate, so it improves 15% strength and steady performance.
- Re-used: Luowen scaffoldings are made by high grade steel, they are not easy to damage or out of shape, so it could be used repeatedly.
Components:
Name | Size | Material | Tube size | Surface | Theoretic weight |
Frame | 1930mm*1219mm | Q345 Steel or Q235 Steel | Φ42*2.4mm | Galvanized | 16.21kg |
1700mm*1219mm | 14.58kg | ||||
1524mm*1219mm | 13.2kg | ||||
1700mm*914mm | 12.84kg | ||||
1700mm*762mm | 10.22kg | ||||
Cross Brace | 1219mm*1829mm | Q345 Steel or Q235 Steel | Φ21*1.5mm | Galvanized | 3.3kg |
1219mm*1524mm | 2.92kg | ||||
1219mm*1219mm | 2.59kg | ||||
914mm*1829mm | 3.06kg | ||||
914mm*1524mm | 2.67kg | ||||
914mm*1219mm | 2.3kg | ||||
610mm*1829mm | 2.89kg | ||||
U-Head Jack | 600mm | Q345 Steel or Q235 Steel | Φ34*4.0mm | galvanized |
|
