Hydraulic Press Deep Drawing

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port Shanghai
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	CNC or Not	CNC
Power Source	Hydraulic	Place of Origin	Zhejiang, China
Brand Name	Xinke	Model Number	Y32
Power(W)	5.5kW-90kW	Weight	40t-1250t
Certification	ISO9001-2000

Product Description

Specifications

Hydraulic Press Deep Drawing
1, intuitive movement
2, high reliability, durability
3, small hydraulic impact

Name: Hydraulic Press Deep Drawing

Characteristics of Hydraulic Press Deep Drawing :

1, Computer optimized design,3-beam&4-column compact structure; 2, Cartridge Valve Integrated System equipped in hydraulic control system with high reliability, durability, small hydraulic impact and minimizing hydraulic impact design;3, Independent electrical control system with reliability, intuitive movement and convenient amendment ;4, Adopting Button common control; 5, Preset Stroke Forming or Preset Pressure Forming process can be selected

Applications of Hydraulic Press Deep Drawing :

Drawing, bending, flanging, cold extruding, blanking processes for metal materials; Adjusting, press-in and forming processes for powder and abrasive products, plastic and insulation materials

Technical Specifications of Hydraulic Press Deep Drawing

Item type		Unit	Y32-40	Y32-63	Y32-100	Y32-125	Y32-200	Y32-315	Y32-400	Y32-500	Y32-630	Y32-800	Y32-1000	Y32-1250
Nominal Pressure		kN	400	630	1000	1250	2000	3150	4000	5000	6300	8000	10000	12500
Ejecting Force		kN	100	160	630	630	800	800	800	1000	1000	1250	2000	2000
Knock-out Force		kN	150	125	160	180	360	450	345	570	850	720	1600	1200
The Max. Pressure of Working Fluid		MPa	25	25	25	25	25	25	25	25	25	25	25	25
The Max. Stroke of Slider		mm	320	500	630	630	710	800	800	900	1000	1000	1000	1000
The Max. Stroke of Ejector		mm	150	160	200	200	250	300	300	300	300	350	450	450
The Max. Opening Height		mm	520	800	900	900	1120	1250	1250	1500	1600	1600	1600	1800
Speed of Slider	Descend	mm/s	55	115	250	220	160	120	180	150	120	150	150	250
	working	mm/s	10-35	10-22	12-40	9-31	7-24	8-20	10-24	10-24	8-18	8-15	5-12	8-15
	Return	mm/s	105	105	200	180	120	120	250	180	125	145	75	140
Speed of Ejector	Ejecting	mm/s	170	90	120	60	60	75	120	65	65	50	60	45
Speed of Ejector	Return	mm/s	450	220	125	125	120	150	120	135	135	120	120	120
Active Area of Working Table(E×D)	Left-Right	mm	450	570	710	710	930	1260	1300	1400	1880	1880	2000	2500
Active Area of Working Table(E×D)	Front-Back	mm	400	500	630	630	900	1200	1300	1400	1600	1600	1800	2000
Overall Dimension	Front-Back	mm	1230	1850	2100	2200	2350	2840	3600	3840	5230	5550	5946	8000
The Height between Working Table and Ground	Left-Right	mm	1234	1855	1880	1880	2000	2000	2600	2800	2800	2600	3135	3400
	Front-Back	mm	1115	2900	3260	3260	3520	4175	4800	4960	5257	5630	5614	7600
	Height above the Ground	mm	870	800	860	860	550	650	710	500	500
Electric Motor Power		kW	5.5	5.5	11	11	15	22	30	44	44	60	74	90
Weight of Machine		t	1.5	2.7	4	41	10	13	17	21	33	43	52	76

Options of Hydraulic Press Deep Drawing :

Cutting Dampening system; Oil heating/cooling unit; Displacement sensor; Industrial touching screen monitor; PLC programmable controller; Floating guide-way and rolling bracket for die exchange; Working area lighting; Quick die clamping device; Light curtain safety device

Products of Hydraulic Press Deep Drawing :
