50-500ml Semi-auto Pneumatic Double Heads Paste Filling Machine

Condition	New		Application	Food, Beverage, Commodity, Medical, Chemical, Other, Food, Beverage, Commodity, Medical, Chemical, Machinery & Hardware
Packaging Type	Cartons		Packaging Material	Paper
Automatic Grade	Semi-Automatic		Driven Type	Pneumatic
Voltage	220V/60Hz, 110V/50Hz		Power	350w
Place of Origin	Guangdong, China		Brand Name	YASON
Model Number	YS-C500		Dimension(L*W*H)	50*46*47
Weight	60KG		Certification	No have
After-sales Service Provided	No overseas service provided

Specifications

1.double heads
2.Stainless Steel
3.Premium configuration
4. Apply for cream, paste, lotion, etc.
5.1- year warranty



50-500ml double heads Cream Shampoo Cosmetic Automatic Filling Machine


♥ Principle ♥



This machine is used for filling cream or paste or liquid with thick-viscosity



machine Parameter:

Voltage: 220V/60Hz, 110V/50Hz
Air pressure: 0.4-0.6MPa
Filling speed: ≤3000pcs/Hour
Hopper Capacity: 30L
Shipping package size 950×420×380mm
Tank shipping package size  450×450×500mm
Filling accuracy: ≤±1%
Filling Range: 50--500ml
Filling Heads: double heads
the weight of the packing machine is  60KG

semi-automatic filling machine piston filler. Driven by a cylinder and piston made from materials with FIVE-way valves control the flow of
materials, and magnetic reed switch control cylinder itinerary can be regulated filling volume.

. Rational design of the aircraft, model compact, easy to operate, are used
pneumatic part of Germany and Taiwan AirTac FESTO the pneumatic components.
. Some contact materials are used 304 stainless steel materials, in line with
the GMP requirements.
. Filling volume and speed of filling can be arbitrary regulation, filling high
accuracy.


Features: This machine adopts full pneumatic control and owns a wide application scope, simple measuring regulation, good shape and convenient cleaning, suitable for the explosion-proof unit.

♥Application ♥


Suitable for medicine,daily life products, food and special industries.And it is an ideal device for adhesive fluid filling.





<1>The machine is suitable for filling food trades(such as: pearl milk tea nata de coco hick broad-bean sauce chili sauce peanut sauce etc);cosmetics(shampoo frost shower gel);daily health product(toothpaste)

<2>The machine adopts pneumatic working principle, simple operation, high filling precision,
 is a certain concentration or certain size granular materials ideal filling  equipment.
