Home > Products > New Products > 15-125kg Automatic Dryer (clothes drying machine)

15-125kg Automatic Dryer (clothes drying machine)

FOB Price

USD $14,980 - $150,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Shanghai, China		Brand Name	BaingQiang
Model Number	GXH-125Q

1.Big heater, big motor ,
2.Good heat efficiency, perfect sealing system
3.New type dryer.

New type dryer

1. Screen :LCD toch screen,simple and convenient to operate.

2. Programs :8 drying programs can be set,suit for different linen.

3. Heaters :Adopt new process heaters and ventilation equipment to realize hot air circulate smoothly ,then increase the drying effect.

4. Capacity: Increase the drum capacity ,enhance the heating consistency.

5. Square punching: Inside roller is square punching.improve the drying efficiency.

6. New:New stype,big fan,big motor,good heat efficiency, perfect sealing system.

Machine Parameter

Moldel	GXH-125Q	Blower Motor(kw*4P)	11
Capacity(KG)	125	Total Capacity(kw)	13.2
Water Evaporation Capacity(kg/hr)	210	Steam Pipe (inch)	2"
Steam Consumption(kg/hr)	400	Cooling Pipe(inch)	1 1/2"
Drum Diameter(mm)	1425	Air Compreesor Pipe(inch)	3/8"
Drum Depth(mm)	1708	Min Steam Pressure(kg/cm²)	7.0
Drum Volume(L)	2700	Air Consumption (NL/time)	40
Ravolution (rpm)	36	Exhaust Pipe Section	ψ620mm or 3020cm²
Drum Punch(m)	12.7(square)	Rated Voltage	380V 50Hz
Blower Air Volume(M3/min)	200	Electric Wiring	10mm²
Front Door(mm)	1100*600	Max Electric Current	30A
Back Door(mm)	ψ1337	Power Switch	70A
Control Mode	touch surface	Dimension (L.W.H) (mm)	296020842885
Drum Motor(kw*4P)	2.2	Total Weight(kg)	2263

Products Image:

Customers:

Company Image:

Production Flow:

Certificates:
