hydraulic bench machines

• APP Series C-frame console pressess are specialized riveting equipments without rivets. In stead of all previous methods which have involved economic and technical problems, they will join different materials by means of a deep drawing-pressing process, and which do so without damage to the surface, purely by displacing and forming.
• It assures you with high productive efficiency as well as full process automaticly monitoring and joining strength checking.
• In the process of pressing , sheet metals of different thicknesses or materials, even with adhesives or other intermediate layers are fully joined.
• In industrial applications,Its available of clinching for single sheet thicknesses of 0.5 mm up to a total layer thickness of 11.0 mm and up to 7500 N tensile strength. In laboratory tests significantly higher values have already been achieved!

Components

• Frame (Cast steel)
• SHINEEAST-Powerpackage  (Series H, P and FT for option )

Our standard function modular as well as the control units are provided for your specific application requirements.

Optional modular

• Two hand safety control modular
• Coupling flange
• Intelligent monitoring
• Processing position indicator

Advantages for a solid connection in detail

• Higher dynamic strength than in spot welding
• On-time monitoring and documented
• Simple, non-destructive quality control is possible
• Optimal corrosion resistance available with galvanized and prepainted materials
• Perfect joints are produced even with narrow flanges and small mounting spaces
• Outstanding conductivity for electric components
• Cold forming process is ideal for hybrid connections (gluing and clinching)

Key features

• Compact structure, clean design
• Increased productivity with automatic feeding system and multi-point riveting
• Large anti-ejecting forces and anti-torsion torques
• High flexibility with height-adjustable
• Lower energy consumption, Lower noise level
• High stroke frequency
• Soft-touch: easy on your tooling
• Easy maintenance and changeable
• Available for riveting nuts diameter larger than M10

Performance parameters

Technical parameters

Please consult us for printable dimensional drawings for APP08 Model .
