Resistive touch panel

Specifications

Resistive touch panel touch screen technology solutions have been applied more and more to industries, applications, products and services, such as car GPS, tablet PC car DVD, PDA, MP5, MP4,learning machine, dictionary, PSP, consumer electronics, moderate to harsh Machine Control, Process Control, System Control/Office Automation and Car PC, etc.

We can custom 4 Wire Resistive 7 inch Touch Screen for you.

Look forward to your specific inquiry!

Specifications:

Our 4 & 5 & 8 Wire Resistive touch screens are available in different sizes from 3.5" to 19". Such as 3.5", 3.6", 3.7", 4.0", 4.2", 4.3", 4.4', 4.5', 4.7", 4.8", 5.0",5.1", 5.2", 5.6", 6.0", 6.2", 6.5", 7.0", 8.0", 9.0",10.1",10.4",12.1",15",17",19...

Type:  4-Wire/5-Wire/8-Wire Analog Resistive Type Touch Panel

Structure:

  Film + Film + FPC

  Film + glass + FPC   ...

The most common application:  GPS & Tablet PC...

Resistive Touch Panel Features:

Proven Resistive Technology

Simplicity of Interface Electronics

Durable Plastic Construction

Less Susceptible to Accidental Touch

Ability to use Finger or Stylus to Activate Touchscreen

High Linear Analog Output

• Optical Specifications:
• • Film type: Anti-glare, Anti-reflective
  • EM/RFI Shielding
  • Contrast Enhancement Filter (CEF) and/or Circular Polarizer
  • Glass, Acrylic or Polycarbonate Backer
  • Light Transmission: 83 ± 5% at 550nm wave length
• Electrical Specifications:
  • Operation Voltage: 5V DC, 1mA
  • Insulation Impedance: 10MΩ or more  25V(DC)
  • Linearity: 98.5% (bias less than 1.5%)
  • Chattering Time: 30 msec or less
• Mechanical Specifications:
  • Input Method: finger, pen or gloved hand
  • Touch Activation Force: 40 grams or less with Æ 2mm Manuscript pen
  • Surface Hardness: 3H (Pencil Test) & Hard Coated ITO PET
• Reliability:
  • Operation Environment: -10°C ~ 60°C
  • Storage Temperature: -20°C ~ 70°C
  • Humidity: 60°C, 90% RH 120 HR
  • Touch Durability: 5 Million touches in a single location
  • Surface scratch: 500K (250g, 60mm/s)
  • Surface pitting: 10M (250g at 2 times/s
